Description
The Huntleigh Dopplex DMX Digital Doppler with Waveform includes a 60 g tube of ultrasound gel, batteries, soft carry bag, and user instruction manual.
Warranty: 3 Years.
The Huntleigh Dopplex DMX Digital Doppler with Waveform gives the clinician objective evidence to assist in the diagnosis of vascular disease that other Dopplers may find difficult or impossible to achieve. Dynamic Digital Noise Reduction (DDNR) system and gel filter optimise the presentation of waveforms and enhance the quality of sound.
Features
Huntleigh Dopplex DMX Digital Doppler with Waveform Features
- High resolution color display with waveforms displayed in high definition and a wide viewing angle.
- Data storage on Micro SD card - store waveforms and sounds for review or transfer to optional DR5 software package for printing reports and archiving.
- Integrated charging and connectivity - USB port for convenient charging and communication with software and stereo headphone connection socket.
- High sensitivity interchangeable probes - All new XS probes have been calibrated and fine-tuned for optimum use.
- Dynamic digital noise reduction reduces the background hiss and the gel filter reduces the loud crackle when gel is applied.
- Bi-directional waveform generated from the Digital Doppler Spectrum with auto scaling features.
- Maximises accuracy and clarity of waveforms; essential for patients with poor blood flow.
- Scroll facility to review your test and choose the ideal waveforms.
- Arterial and venous models.
Specifications
Huntleigh Dopplex DMX Digital Doppler with Waveform Specifications
- High Resolution Color Display: Included.
- Bi-directional Doppler Waveform Display: Included.
- Noise Reduction: DDNR.
- Removable Micro SD Card Storage: Included.
- Scroll Memory: 20 Seconds.
- Timebase: 3, 6, and 12 seconds.
- Compatible with Interchangeable XS Probes: Yes.
- Integrated Loudspeaker: Yes.
- Flow Separated Stereo Headphone Output: Yes.
- Gain Control: Auto.
- USB Capability: Micro.
- Battery Type: 2 x AA Alkaline batteries
- Battery Life (number of 1 minute exams): 500.
- Weight: 310 grams (11 oz).
- Dimensions:
- Height: 140 mm (5.5”).
- Width: 75 mm (3.0”).
- Depth: 30 mm (1.2”).
- Safety Standard Compliance: IEC 60601-1: Edition 3.1, ANSI/AAMI ES 60601-1:2005., CAN/CSAC22.2 No 60601-1:14., IEC 60601-1:1998+A2:1995 (2nd Edition), JIS T 0601-1:2012, EN 60601-1-11:2015, EN 60601-2-37:2008+A11:2011., IEC 60601-1-2:2014.
Configurations
Huntleigh Dopplex DMX Digital Doppler with Waveform Configurations
- #DMX-USA: Standard Battery.
- #DMXR-USA: Rechargeable Battery.
