BD Alaris 8210 Nellcor SPO2 Module

BD Alaris 8210 Nellcor SPO2 Module Features

• Ensures safety throughout the duration of infusion therapy.
• Automatically pause a PCA infusion and deactivate the patient dose request cord if a patient falls below your hospital-defined % SpO limits.
• SatSeconds is an alarm management tool that allows you to configure the time that the %SpO level may fall outside the alarm limit before an audible alarm sounds.
• Pre-Silence feature enables alarms to be pre-silenced for 120 seconds. Silence can be canceled before the 120 seconds are complete.
• Supports current ASA and APSF standards mandating monitoring of oxygenation for all appropriate patients.

BD Alaris 8210 Nellcor SPO2 Module Specifications

Dimensions:

• Height: 8.9 inches (22.6 cm).
• Width: 3.3 inches (8.4 cm).
• Depth: 5.5 inches (14 cm).
• Weight: 2 lb (0.91 kg).

Accuracy and Motion Tolerance:

• Pulse Rate:
• Low Perfusion1 20 – 250 bpm, ±3 digits.
• Motion normal physiologic range (55 -125 bpm) ±5 digits.
• No Motion1 20 – 250 bpm, ±3 digits.
• Functional Saturation:
• Low Perfusion1 70 – 100%, ±2 digits.
• Motion2.
• Adults and Neonates 70 – 100%, ±3 digits.
• No Motion3.
• Adults 70 – 100%, ±2 digits.
• Neonates 70 – 100%, ±3 digits.
• IPerfusion 0.03 to 20%.
• IPulse Rate 20 to 250 bpm.
• ISpO2 1 to 100%.

Alarms:

• Audible and visual alarms for high and low saturation and pulse rate, sensor condition, system failure, and low battery conditions.

Alarm Limits:

• Pulse Rate: Low – 30-239 BPM. High – 31-240 BPM.
• SpO: Low – 20-99% High – 21-100%.

Measurement Range:

• Perfusion: 0.03 to 20%.
• Pulse Rate: 20 to 250 BPM.
• SpO: 1 to 100%.
