BD Alaris 8300 SpO2 Module

BD Alaris 8300 SpO₂ Module Features

• Reduces the risks of opioid infusions.
• Customizable profiles provide flexibility across all patient-care areas.
• Sampling lines reduce the need for moving parts, external sensors or routine calibration.
• Features two IUI Connectors (left and right).
• Utilizes three status indicators - alarm (red), monitoring (green), and standby (yellow).
• EtCO₂ mmHg display, respiratory rate display, channel (module) message display, and channel (module) identification make for added convenience.
• Microstream Disposable Connector.
• Gas Exhaust or gas scavenging system connection.
• Pressing the module release latch allows the module to be removed.

BD Alaris 8300 SpO₂ Module Specifications

• Accuracy: Respiration rate, measured in range of 0 - 150 bpm with following accuracy
• 0 - 70 bpm: ± 1 bpm.
• 71 - 120 bpm: ± 2 bpm.
• 121 - 150 bpm: ± 3 bpm.
• Alarms: Audible and visual alarms for high and low EtCO₂ and respiratory rate, high FiCO₂, Microstream Disposable condition, system failure, no breath, and low battery conditions.
• Barometric Pressure: EtCO₂ module is equipped with automatic barometric pressure compensation. There are no quantitative effects of barometric pressure for this device.
• CO₂ Range: Measures and reports partial pressures of CO₂ in the range of 0 - 99 mmHg at sea level. EtCO₂ and FiCO₂ values are calculated for all valid breaths.
• Dimensions: 3.3" (W) x 8.9" (H) x 5.5" (D) (8.4 cm x 22.6 cm x 14 cm).
• Flow Rate: Nominally 50 mL/min -7.5 +15 mL/min.
• Fluid Ingress Protection: IPX1, Drip Proof.
• Frequency Response: EtCO₂ accuracy applies for breath rates of up to 80 bpm. For maintaining accuracy for respiration rates above 80 bpm, accuracy is 4 mmHg or ± 12% of reading, whichever is greater, for EtCO₂ values exceeding 18 mmHg. To achieve specified accuracies for breath rates above 60 bpm, Microstream neonatal airway adapter M1996A must be used.
• Gas Interference: Following liquid anesthetics have been tested and were found to have no effect:
• Desflurane.
• Enflurane.
• Halothane.
• Isoflurane.
• Sevoflurane.
• Internal Power Source: Operating time (fully charged): 5.5 hours.
• Measurement Range:
• EtCO₂: 0 - 99 mmHg.
• FiCO₂: 0 - 99 mmHg.
• Respiratory Rate: 0 - 150 bpm.
• Mode of Operation: Continuous.
• Shock Protection: Type BF, Defibrillator Proof patient applied part.
• System Response Time:
• EtCO₂ Module Response: 2.9 seconds typical (includes rise time of 190 msec maximum and delay time of 2.7 seconds typical).
• PC Unit Display Response: Approximately a half-second longer than EtCO₂ module response.
• Warm-Up Time: 30 seconds typical.
• Weight: 2.5 lb (0.91 kg).

BD Alaris 8300 SpO₂ Module Literature

BD Alaris 8300 SpO₂ Operators Manual
