Description
The Allied Healthcare LSP All-Brass Regulators come equipped with DISS check valves, and provide regulated pressure and flow for operation of two demand valves, one demand valve and one aspirator, or a pneumatically-powered ventilator.
Warranty: 5 Years.
The LSP All-Brass Regulators feature uni-body construction that strengthens the regulator, minimizes leak paths, and prevents breakage of the yoke cylinder connection assembly. They're resilient to normal wear and tear, including resistance to corrosive materials. For additional safety, inlet filters provide gas filtration down to 20 microns. The regulator has a large, easy to read gauge, and a DISS outlet to attach masks, cannula, bag masks, and more. In fact, all outlets can operate simultaneously without interruption.
Features
Allied Healthcare LSP All-Brass Regulator Features
- 12 Flow Positions.
- Large easy to read flow rate numbers.
- Uni-body construction that strengthens the regulator.
Specifications
Allied Healthcare LSP All-Brass Regulator Specifications
- Supply Pressure: 500 - 2000 psi.
- Outlet Pressure: High flow 40 - 60 psi @ 500 - 2200 psi input.
- Filter: 25 micron sintered bronze.
- Safety Relief Pressure: 75 - 125 psi.
- Operating Temperature: -30 to 125 °F.
- Storage Temperature: -20 to 120 °F.
- Materials:
- Body - nickel-plated brass.
- Knob - anodized aluminum.
- Outlets - nickel-plated brass.
- Internal Parts - brass, stainless steel, Viton, silicon, and Teflon.
Configurations
Allied Healthcare LSP All-Brass Regulators Configurations
| MPN | Items Included | Type | Flow |
|---|---|---|---|
| #L106-260 | 2 Check Valves | DISS Fitting CGA 540 Regulator | Fixed Flow |
| #L270-220 | 2 Check Valves, Hose Barb Outlet | Yoke Pin Indexed CGA 870 Regulator | 0 - 25 lpm |
| #L270-220-CE | 2 Check Valves, Hose Barb Outlet | Yoke Pin Indexed CGA 870 Regulator | 0 - 25 lpm |
| #L270-230 | 2 Check Valves, Hose Barb Outlet | Yoke Pin Indexed CGA 870 Regulator | 0 - 15 lpm |
| #L270-250 | Hose Barb Outlet | Yoke Pin Indexed CGA 870 Regulator | 0 - 25 lpm |
| #L270-260 | Hose Barb Outlet | Yoke Pin Indexed CGA 870 Regulator | 0 - 15 lpm |
| #L280-220 | 2 Check Valves, Hose Barb Outlet | DISS Fitting CGA 540 Regulator | 0 - 25 lpm |
