TransMotion Medical TMM4 Multi-Purpose Stretcher-Chair

Name: TransMotion Medical TMM4 Multi-Purpose Stretcher-Chair
Brand: TransMotion Medical
SKU: MFI-TMM-TMM4-XB
Price: 3881.16 USD
Availability: InStock

TransMotion Medical TMM4 Multi-Purpos...

Liquid error (snippets/ced-product-media line 158): external_video_tag does not support String

Key Features

SKU: MFI-TMM-TMM4-XB
Condition:

Condition: Certified Refurbished

Condition: Certified Refurbished

Condition: Certified Refurbished

Condition: Certified Refurbished

Condition: Certified Refurbished

Condition: Certified Refurbished

Condition: Certified Refurbished

Condition: Certified Refurbished

Condition: Certified Refurbished

Condition: Certified Refurbished

Condition: Certified Refurbished

Condition: Certified Refurbished

Condition: Certified Refurbished

Condition: Certified Refurbished
Warranty:

Warranty: 90 Days

Warranty: 90 Days

Warranty: 90 Days

Warranty: 90 Days

Warranty: 90 Days

Warranty: 90 Days

Warranty: 90 Days

Warranty: 90 Days

Warranty: 90 Days

Warranty: 90 Days

Warranty: 90 Days

Warranty: 90 Days

Warranty: 90 Days

Warranty: 90 Days
Weight: 312.0 lb
Requires half the space of a traditional stretcher and is easy to navigate through hallways, rooms, elevators, and other close quarters
All metal surfaces for a long, durable life
Auto-Extending Foot Rest improves patient comfort in all positions
Easy Mobility brake and steer caster system
Learn more:

Contact The Manufacturer

MFR: TransMotion Medical

Ships from MFI Medical

Ships from MFI Medical

Ships from MFI Medical

Ships from MFI Medical

Ships from MFI Medical

Ships from MFI Medical

Ships from MFI Medical

Ships from MFI Medical

Ships from MFI Medical

Ships from MFI Medical

Ships from MFI Medical

Ships from MFI Medical

Ships from MFI Medical

Ships from MFI Medical

Items shipped from the manufacturer

This item will be shipped directly from the manufacturer to your doorstep, ensuring that you receive the newest product available. The estimated delivery range provided is based on the manufacturer's inventory levels and is subject to change depending on the quantity ordered. We ship items as soon as they become available, so if you order multiple quantities, you may receive them in separate shipments.

Special order item

A special order item will need to ship to our warehouse from the manufacturer before then shipping to you. The estimated delivery range that you see is based on the information that we receive from the manufacturer, which is also contingent upon your ordered quantity and the current inventory levels of the manufacturer. We will ship the items to you as soon as they become available, which may result in multiple shipments if you order more than one quantity.
MPN: TMM4-XB

MPN: TMM4-WTB

MPN: TMM4-XWA

MPN: TMM4-LB

MPN: TMM4-QB

MPN: TMM4-TLB

MPN: TMM4-WT

MPN: TMM4-XWTA

MPN: TMM4-XWTB

MPN: TMM4-B

MPN: TMM4-WTR

MPN: TMM4-XBW

MPN: TMM4-WB

MPN: TMM4-XTB
Phone: (800) 237-3377

$3,881.16

Select a Configuration

Variant

1+ In Stock

Est. Delivery:

Quantity

%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E

Shop with Confidence

Description

The TransMotion Medical TMM4 Multi-Purpose Stretcher-Chair includes a new mattress pad and a handheld operating pendant.

Warranty: 90 Days - Parts and Labor.

Note: For configurations that feature AC power, the AC power cord allows you to charge the internal battery while the stretcher is still in use.

The TMM4 is a treatment chair, transport device, procedure device, surgical table, recliner, and a stretcher, all in one (known as the Universal Care Platform). It helps reduce staff injury, patient fall risk, and improve patient throughput. Patients can go from admission to procedure, to discharge, all on one surface with no transfers.

Common Applications: Emergency/Triage, Radiology, ICU/CCU, Audiology, Dialysis, Endoscopy/G.I., ENT, Mammography, Oncology, Orthopedic Surgery, Outpatient Surgery, Pre-Op/PACU, Rehab, Respiratory/Bronchoscopy, Safe Patient Handling, Transport, Wound Care, and more.

The TransMotion Medical TMM4 Multi-Purpose Stretcher-Chair reduces occupational injuries and maximizes space for increased patient capacity. When in seated position, the TMM4 requires half the space of a traditional stretcher and is easy to navigate through hallways, rooms, elevators, and other close quarters.

Battery operated controls provide exceptional powered positioning of back, leg, and height for safe patient transport and treatment. A manual quick release backrest is also included as a backup.

Auto-contour button automatically positions the chair from seated to the fully reclined position. A full Radiolucent Back Section allows for X-Ray, fluoroscopic, and C-arm radiologic procedures.

Features

TransMotion Medical TMM4 Multi-Purpose Stretcher-Chair Features

Self-Storing Push Bars swing out of the way for an unobstructed view of the patient.
Cushioned, Chrome Side Rails protect the patient during transport and procedures, then swing down and tuck away for easy patient side ingress and egress.
All Metal Surfaces for a long, durable life.
Auto-Extending Foot Rest improves patient comfort in all positions.
Easy Mobility brake and steer caster system.
Space saving footprint allows for more units to be available for patients, as well as easier storage. The TMM4 requires half the space of a traditional stretcher and is easy to navigate through hallways, rooms, elevators, and other close quarters.
Adjustable Seat Height (options): Hand control pendant makes it easy for the caregiver to adjust the patient's seated chair height.
- Standard: Double column adjusts the height of the chair from 25 to 33".
- Tall (optional): Triple column adjusts the height of the chair to a tall position of 24 to 40".
- Low (optional): Adjustable low option allows the chair to be adjusted to an even lower height of 23.5", standard 25".
X-Seat Tilt (optional): Sought after reclined and knee-flex positioning perfect for many outpatient surgical procedures and pressure point relief for patients.
- Precise patient positioning with knee gatch feature for procedures and surgery.
- 20° Trendelenburg and 5° reverse Trendelenburg in stretcher position.
- 3" longer wheelbase.
- Comfortable recline positioning.
- Brakes located in the middle.
- 73" patient surface length.

Specifications

TransMotion Medical TMM4 Multi-Purpose Stretcher-Chair Specifications

Maximum Patient Weight: 500 lb (227 kg).
Radiolucent Back: 20" (W) x 25.5" (H).
Side Rails:
- Height: 13" (32 cm).
- Length: 26" (66 cm).
Charging System:
- Input:
  - Volts: 100 - 240 VAC.
  - Current: 1.0 A (max).
  - Frequency: 50/60 Hz.
- Output: +24 V DC 1.5 a.
- Max Power: 36 W.

Models	#TMM4-B	#TMM4-WTB	#TMM4-XB	#TMM4-LB	#TMM4-TLB
Seat Height - Low (Below Cushion)	21" (54 cm)	21" (53 cm)	21" (54 cm)	20" (50 cm)	19" (49 cm)
Seat Height - Low (Above Cushion)	25" (64 cm)	25" (62 cm)	25" (64 cm)	24" (60 cm)	23" (58 cm)
Seat Height - High (To Seat Pan)	29" (74 cm)	37" (93 cm)	29" (74 cm)	28" (70 cm)	35" (89 cm)
Seat Height - High	33" (84 cm)	40" (106 cm)	33" (84 cm)	32" (80 cm)	40" (100 cm)
Patient Seat Width	24" (61 cm)	28" (71 cm)	24" (61 cm)	24" (61 cm)	24" (61 cm)
Patient Surface Length	77" (195 cm)	77" (195 cm)	72" (184 cm)	72" (184 cm)	72" (184 cm)
Overall Width	30" (76 cm)	34" (87 cm)	30" (76 cm)	30" (76 cm)	30" (76 cm)
Overall Chair Height - High	62" (157 cm)	70" (178 cm)	63" (159 cm)	62" (157 cm)	68" (174 cm)
Overall Chair Height - Low	54" (137 cm)	53" (135 cm)	55" (139 cm)	52" (133 cm)	52" (131 cm)
Backrest Articulation	0 to 75°	0 to 75°	0 to 86°	0 to 75°	0 to 75°
Trendelenburg	5°	5°	20°	5°	5°
Reverse Trendelenburg	0°	0°	5°	0°	0°

Configurations

TransMotion Medical TMM4 Multi-Purpose Stretcher-Chair Configurations

#TMM4-B: Standard.
#TMM4-XB: with X-Seat Tilt recliner.
#TMM4-LB: with Adjustable Height (Low) - Allows the chair to be adjusted to a low seat height of 23.5", standard 25".
#TMM4-WB: with Wide Patient Seat Width (28") and battery power.
#TMM4-WTB: with Wide Patient Seat Width (28") and Adjustable Height (Tall) - Standard patient seat width 28". Allows the chair to be adjusted to a high seat height of 40", standard 33". Battery power.
#TMM4-TLB: with Adjustable Height (Low) and Adjustable Height (Tall) - Allows the chair to be adjusted from a height range of 23.5 to 40", the standard is 25 to 33".
#TMM4-XWTB: with X-Seat Tilt recliner. Wide Patient Seat Width (28") and Adjustable Height (Tall) - Standard patient seat width 28". Allows the chair to be adjusted to a high seat height of 40", standard 33".
#TMM4-WT: with Wide Patient Seat Width (28") and Adjustable Height (Tall) - Standard patient seat width 28". Allows the chair to be adjusted to a high seat height of 40", standard 33".
#TMM4-WTR: with Wide Patient Seat Width (28"), Adjustable Height (Tall) - Standard patient seat width 28". Allows the chair to be adjusted to a high seat height of 40", standard 33", and Upper Rails.
#TMM4-XWTA: with X-Seat Tilt recliner. Wide Patient Seat Width (28") and Adjustable Height (Tall) - Standard patient seat width 28". Allows the chair to be adjusted to a high seat height of 40", standard 33". AC Power.
#TMM4-QB: with scale and battery power.
#TMM4-XWA: with X-Seat Tilt, Wide Patient Seat Width (28"), and AC Power.
#TMM4-XBW: with Wide Patient Seat Width (28"), X-seat tilt, and battery power.
#TMM4-XTB: with X-Seat Tilt, battery power, and adjustable height (Tall) - Standard patient seat width 28". Allows the chair to be adjusted to a high seat height of 40", standard 33".

Literature

TransMotion Medical TMM4 Multi-Purpose Stretcher-Chair Literature

TransMotion Medical TMM4 Plus-X Series Operation Manual

Frequently asked questions

What makes the TMM4 a Universal Care Platform?

The TransMotion Medical TMM4 is designated a Universal Care Platform because it combines the functionality of several medical devices into a single unit. This innovative design allows patients to remain on the same surface from admission through discharge, eliminating unnecessary transfers and improving safety.

Key functions and benefits that define its versatility include:

<ul>
<li>All-in-One Functionality: The unit functions as a stretcher, treatment chair, recliner, transport device, surgical table, and procedure table.</li>
<li>Reduced Transfers: Minimizing patient transfers drastically lowers the risk of patient falls and reduces potential occupational injuries for staff.</li>
<li>Radiology Ready: It features a full Radiolucent Back Section (20” W x 25.5” H), making it suitable for diagnostic procedures including X-ray, fluoroscopic, and C-arm imaging.</li>
<li>Space Efficiency: When in the seated position, the TMM4 requires only half the floor space of a traditional stretcher, enhancing maneuverability in tight clinical quarters.</li>
</ul>

Does the TMM4 optimize clinical space?

Yes, the TransMotion Medical TMM4 is engineered as a Universal Care Platform specifically designed to maximize space efficiency and enhance patient throughput.When converted into its seated position, the TMM4 requires half the floor space of a traditional stretcher.This compact footprint provides significant operational benefits, especially in crowded clinical settings:<ul><li>Enhanced Maneuverability: Allows staff to navigate easily through tight spaces, such as hallways and elevators.</li><li>Better Utilization: Maximizes the available clinical floor space by combining multiple functions (chair, stretcher, procedure table) into one unit, reducing the need for transfers.</li></ul>

Does the TMM4 include a radiolucent back section?

Yes, the TransMotion Medical TMM4 is specifically equipped with a full Radiolucent Back Section.

This feature is a key component of its design as a Universal Care Platform, allowing staff to perform various imaging procedures without having to transfer the patient to a separate table. This capability significantly reduces patient risk and improves clinical workflow.

The radiolucent back is designed to support:
<ul>
<li>X-ray procedures</li>
<li>Fluoroscopic procedures</li>
<li>C-arm radiologic procedures</li>
</ul>

The precise dimensions of the radiolucent area are 20 inches (W) x 25.5 inches (H).

What is the maximum patient weight capacity?

The TransMotion Medical TMM4 Multi-Purpose Stretcher-Chair is built for safety and durability, offering a robust weight capacity suitable for a wide range of patients and clinical applications.The maximum patient weight capacity is:

<ul>
<li>500 lb (227 kg)</li>
</ul>

Does the TMM4 have powered height adjustment?

Yes, the TransMotion Medical TMM4 features advanced battery-operated controls for precise powered positioning, including height adjustment. This system is designed to minimize staff strain and enhance patient safety.

All primary movements are managed via the included handheld operating pendant, which controls:

<ul>
<li>Height Adjustment: The chair offers adjustable height ranges (Standard, Low, Tall, or a combination).</li>
<li>Back and Leg Articulation: Powered adjustment for backrest and leg sections.</li>
<li>Auto-Contour Feature: Allows for a seamless, smooth powered transition from a seated position to fully reclined with a single button press.</li>
</ul>

An integrated manual quick-release mechanism for the backrest is included as a safety backup.

Does it have a backup for the powered controls?

Yes, the TMM4 is designed with clinical reliability in mind. While the primary positioning is handled by a convenient battery-operated handheld pendant, it also includes a manual quick-release backrest backup to ensure patient safety and staff control even if the battery or power system is unavailable.

What are the safety side rail dimensions?

The safety side rails are designed to enhance patient safety during transport and positioning. They are cushioned and can be tucked away for easy access.

Their specific dimensions are:

<ul>
<li>Length: 26 inches (66 cm)</li>
<li>Height: 13 inches (32 cm)</li>
</ul>

Does the TMM4 include an auto-extending footrest?

Yes, the TransMotion Medical TMM4 Multi-Purpose Stretcher-Chair includes an Auto-Extending Foot Rest.

This comfort feature ensures continuous and proper patient support as the unit transitions between seated and fully reclined stretcher configurations, minimizing the need for manual staff adjustments.
