Maxtec MAX-13C Oxygen Cell

Maxtec MAX-13C Oxygen Cell
Key Features
  • SKU: CAS-G0-140
  • Condition:
    Condition: Factory New
  • Warranty:
    Warranty: 16 Months
  • Weight: 0.25 lb

  • Learn more:

Contact The Manufacturer
  • MFR: Maxtec
    Ships from Manufacturer
  • MPN: G0-140
  • Phone: (800) 748-5355
$144.14

+ Free Shipping

Select a Configuration
Est. Delivery:

Shop with Confidence

Free Shipping

+

Free Returns

Payment Options

+

Price Match

Description

This Maxtec MAX-13C O2 Cell is an FiO2 (Fraction of Inspired Oxygen) Sensor that is a compatible replacement for the Maxtec MAX-13C or Nuova E-14/0 Oxygen Sensors. It is compatible with Maxtec and Nuova systems. Primarily used with Ventilation Machines and O2 Monitors / Analyzers, see below for specific compatibility information.

*Note: Can only be shipped within the U.S.

Maxtec MAX-13C O2 Cell Specifications:


  • Compatible with:
    • BioMed Devices (4433).
  • G0-140 (Mextec Equivalent) Specifications:
    • Response Time: < 12 seconds.
    • Connector Type:0.141" Miniature phone plug on cable.
  • R115P01 (Maxtec) Specifications:
    • Output: 13.0 to 17.0 mV.
    • Response Time: ‰¤ 13 seconds.
    • Linearity: < 3% error.


Maxtec MAX-13C O2 Cell Configurations:


  • G0-140: MAX-13C Cell Equivalent manufactured by Cables and Sensors.
    • Warranty: 16 Months.
  • R115P01: Maxtec MAX-13C Cell manufactured by Maxtec.
    • Warranty: 14 Months.


Maxtec MAX-13C O2 Cell Literature:


Maxtec KOH Oxygen Sensors Safety Data Sheet

Maxtec MAX-13C Oxygen Cell Specifications Sheet

Frequently asked questions

Does this O2 cell offer broad compatibility?

Yes, the Maxtec MAX-13C Oxygen Cell is designed for broad system compatibility as a crucial FiO2 (Fraction of Inspired Oxygen) sensor in medical settings. It is intended for use with:

  • Ventilation Machines
  • O2 Monitors / Analyzers

This sensor serves as a direct, compatible replacement for:

  • Maxtec MAX-13C sensors
  • Nuova E-14/0 sensors

It is compatible with various systems from Maxtec and Nuova, and is explicitly listed for use with the BioMed Devices 4433 model.

What factor does this oxygen cell measure?

The Maxtec MAX-13C Oxygen Cell is an electrochemical sensor designed to measure the Fraction of Inspired Oxygen (FiO2). This is a crucial metric that quantifies the oxygen concentration delivered within a monitored system.

The sensor is primarily engineered for use in professional medical devices, including:

  • Ventilation Machines
  • O2 Monitors / Analyzers

It serves as a high-quality replacement, compatible with original Maxtec MAX-13C or Nuova E-14/0 Oxygen Sensors.

Does the equivalent O2 sensor have a fast response time?

Yes, the equivalent MAX-13C Oxygen Cell (G0-140), manufactured by Cables and Sensors, offers rapid performance for FiO2 monitoring. Here are key specifications:

  • Response Time: Less than 12 seconds, providing quick results.
  • Connector: Features a 0.141” miniature phone plug on the cable for easy installation.
  • Warranty: Comes with a 16-month warranty.
What is the output range for the original Maxtec cell?

The Original (Maxtec Brand) R115P01 oxygen cell provides an electrical output range of 13.0 to 17.0 mV.

This Maxtec configuration offers high-quality performance metrics, including:

  • Response Time: 13 seconds or less
  • Linearity: Less than 3% error
What connector type does the equivalent sensor use?

The equivalent sensor configuration, manufactured by Cables and Sensors (G0-140), uses a specific connection type for reliable integration with medical monitoring systems. It features a 0.141” Miniature phone plug located on the attached cable, ensuring seamless connectivity to compatible O2 monitors and ventilation machines.

Does the Original Maxtec Cell offer high linearity?

Yes, the Original (Maxtec Brand) MAX-13C Oxygen Cell (MPN: R115P01) is specifically engineered for high accuracy and minimal measurement deviation.

Its linearity specification is defined as less than 3% error (< 3% error), ensuring highly reliable and consistent measurement of the Fraction of Inspired Oxygen (FiO2) in critical respiratory applications.

Is the Maxtec MAX-13C Oxygen Cell a new or refurbished product?

The Maxtec MAX-13C Oxygen Cell is factory new.

Can this oxygen cell be shipped internationally?

No, this oxygen cell can only be shipped within the United States.

Are there different configurations available?

Yes, the Maxtec MAX-13C Oxygen Cell is available in two configurations:

  • MAX-13C Cell Equivalent (G0-140)
  • Original Maxtec Brand (R115P01)

This provides flexibility based on your specific needs.

What medical devices use this high-quality sensor?

This FiO2 (Fraction of Inspired Oxygen) sensor is designed for critical clinical applications, primarily in:

  • Ventilation Machines
  • O2 Monitors / Analyzers

It functions as a direct, compatible replacement for the original Maxtec MAX-13C and Nuova E-14/0 Oxygen Sensors, ensuring broad compatibility across both Maxtec and Nuova systems.
