The Unico IP730 utilizes a 4-hole reverse nosepiece and includes standard magnifications of 4X, 10X, 40X, and 100X (Oil immersion) across all models.

The primary difference between configurations lies in the optical quality of the objectives. The IP730 series offers the following objective types (two currently available):

• Achromat Objectives (IP730): This is the standard configuration, ideal for routine laboratory work, education, and general screening.
• Plan Achromat Objectives (IP730PL): This premium configuration provides the highest level of optical performance. It ensures a superior, flat field of view from edge-to-edge, which is essential for critical viewing, precise measurements, and high-quality documentation.

(Note: The Semi-Plan Achromat objective configuration (IP730SP) is listed as discontinued.)

The Unico IP730 offers versatile objective configurations, all featuring standard magnifications of 4X, 10X, 40X, and 100X (Oil). You can customize the microscope by selecting the objective type that best meets your imaging requirements:

• Achromatic Objectives: These are the standard option, designed for reliable optical performance suitable for routine clinical and general laboratory use.
• Plan Achromatic Objectives: This is the highest available optical grade. Plan objectives ensure superior clarity and provide a completely flat field of view across the entire specimen. This high level of correction is ideal for critical imaging, advanced research, and photomicrography.

The Unico IP730 features a robust construction, contributing to its stability during extended laboratory use, with a unit weight of 18 lbs.

Its overall physical dimensions are:

• Length: 10 inches
• Width: 8.5 inches
• Height: 15.4 inches

The Unico IP730 Advanced Binocular Microscope includes several essential accessories for protection, maintenance, and operation:

• Dust Cover: Protects the unit from dust and debris when stored or not in use.
• Blue Filter: Used to optimize illumination and enhance contrast when viewing specimens.
• Two extra Fuses: Provided to ensure maintenance and continued functionality of the electrical system.
• Operation Manual: Contains comprehensive instructions for setup, usage, and long-term care.

The Abbe condenser, with a numerical aperture (NA) of 1.25, is designed to focus and control the light that illuminates the sample. It features:

• Graduated Iris Diaphragm: Controls the amount of light passing through.
• Filter Holder: Allows for the insertion of filters to modify the light.
• Centerable Adjustment: Ensures optimal alignment for even illumination.

Yes, the Unico IP730 Advanced Binocular Microscope is specifically designed for demanding environments, making it highly suitable for educational institutions, clinical settings, and professional laboratories. Its robust features prioritize long-term performance and user comfort during extended observation periods.

Key features that make it ideal for learning and professional work include:

• Ergonomic Comfort: It features a Seidentopf binocular head and a low-position coaxial focusing system with tension control, which significantly minimizes user fatigue.
• Precision Focusing: The fine focusing system offers exceptional precision, graduated to 0.002 mm.
• Versatile Optics: The microscope is available with various objective types, including standard Achromat objectives and high-performance Plan Achromat options (4X, 10X, 40X, 100X oil immersion) to meet different observational needs.
• Advanced Illumination: It provides professional Koehler Type Illumination through a built-in illuminator and a focusable/centerable Abbe Condenser (NA 1.25), ensuring clear, even, and high-contrast light.
• Durable Construction: The large, heavy-duty mechanical stage (180mm x 150mm) is built to last and provides precise, graduated X-Y specimen control.

Yes, the Unico IP730 utilizes a built-in illumination system engineered for precision and clarity:

• Koehler Type Illumination: This advanced style uses a field diaphragm to ensure bright, uniform, and high-contrast lighting across your entire specimen, which is essential for high-resolution work.
• Focusable Abbe Condenser: Illumination is routed through a focusable and centerable Abbe Condenser (NA 1.25), which includes a graduated iris diaphragm and filter holder for precise light control.
• Variable Brightness: A variable intensity rheostat wheel, located on the base, allows for quick and easy adjustment of light brightness.

The interpupillary distance adjustment range is 55-75mm. This allows users to adjust the distance between the eyepieces for comfortable viewing, accommodating different individual needs.

Yes, the Unico IP730 is designed for universal compatibility, allowing it to be used across various regions and electrical systems.

Key details regarding its power system include:

• Voltage Range: It operates on a broad input range from 110V-60Hz to 240V-50Hz.
• Safety & Certification: The electrical parts are UL & CSA Approved, ensuring compliance with high safety standards.
• Connection: The microscope utilizes a three-wire grounded electric cord for secure and reliable power.

The Unico IP730 features a low-position coaxial coarse and fine focusing system with coarse focus tension control. The fine focusing is graduated at 0.002 mm, allowing for precise adjustments and reducing user fatigue.
