Condition:
Factory New
- Country of Origin: Mexico
-
Warranty:
1 Year
- Weight: 1.75 lb
- Provides a clear, continuous capnogram of carbon dioxide values
- Designed to fit easily onto a breathing circuit
- No routine calibration required
- Minimal warm-up time, with EtCO2 and respiration rate measurements and real-time EtCO2 waveform displayed in 15 seconds
-
Learn more:
-
MFR:
Masimo
Ships from MFI Medical
- MPN: 3639
- Phone: (800) 326-4890
+ Free Shipping
Frequently asked questions
Does this capnograph support all patient sizes?
Yes, the Masimo EMMA Capnograph is designed for versatile use, supporting continuous monitoring across all major patient populations:
- Adult Patients
- Pediatric Patients
- Infant Patients
This broad compatibility makes the device highly effective for rapid assessment in diverse acute care environments.
Note on Airway Adapters:
While the device is universally compatible, accurate readings depend on connecting the correct size accessory. Patient-size-specific EMMA Airway Adapters (available for Adult/Pediatric and Infant use) are required for proper operation and are sold separately.
Does the EMMA Capnograph provide rapid results?
Yes, the Masimo EMMA Capnograph is specifically designed for rapid, immediate monitoring and responsiveness.
It achieves full measurement accuracy and delivers vital respiratory data—including End-tidal Carbon Dioxide (EtCO2) and Respiration Rate (RR) measurements, along with a real-time capnogram waveform—in just 15 seconds after warm-up.
This rapid response time makes it ideal for use in time-critical environments like Emergency Medicine, Operating Rooms, and pre-hospital care.
Does the EMMA Capnograph have comprehensive alarms?
Yes, the Masimo EMMA Capnograph features a comprehensive audible and visual alarm system to ensure patient safety and reliable operation across acute care settings. It helps clinicians monitor critical parameters in real-time.
The key alerts monitored by the device include:
- Apnea: Alerts when the absence of breathing is detected.
- Adjustable High/Low $\text{EtCO}_2$: Triggers if end-tidal carbon dioxide values exceed or fall below user-defined thresholds.
- Airway Adapter Warnings: Alerts for both No Adapter and Clogged Adapter conditions, which helps maintain circuit integrity.
- Low Battery: Provides notification when the device power is running low.
Does the Masimo EMMA Capnograph require routine calibration?
No, the Masimo EMMA Capnograph does not require routine calibration, which simplifies its use and maintenance in various clinical settings.
Does the EMMA Capnograph offer continuous monitoring?
Yes, the Masimo EMMA Capnograph is designed specifically for continuous, real-time measurement of End-Tidal Carbon Dioxide ($ ext{EtCO}_2$) and respiration rate (RR). It is engineered for rapid deployment and ongoing monitoring in various acute care settings.
The continuous monitoring capability is supported by several key features:
- Rapid Readiness: The device has a minimal warm-up time, displaying measurements and a real-time $ ext{EtCO}_2$ waveform in just 15 seconds.
- Low Maintenance Operation: The EMMA Capnograph requires no routine calibration for reliable continuous operation.
- Comprehensive Alarms: To ensure patient safety during continuous monitoring, the unit features audible and visual alarms for:
- Apnea
- Low Battery
- Clogged or Missing Adapter
- Adjustable High and Low $ ext{EtCO}_2$ limits.
- Continuous Data: It provides quantitative $ ext{EtCO}_2$ (in $ ext{mmHg}$ or $ ext{kPa}$) and respiration rate, along with a 14.4-second sweep waveform.
How long do the batteries last?
The EMMA Capnograph is powered by two AAA batteries (two are included in the kit).
Operational time depends on the type of battery used, with Lithium recommended for the longest runtime:
- Lithium Batteries (Recommended): Provides up to 10 hours of normal use.
- Alkaline Batteries: Provides up to 6 hours of normal use.
Is the Masimo EMMA Capnograph highly versatile?
Yes, the Masimo EMMA Capnograph is highly versatile and designed for use in a variety of clinical settings, including:
- Pre-hospital environments
- Emergency medicine
- Operating rooms
- Intensive Care Units (ICUs)
- Long-term acute care facilities
Its compact and robust design ensures reliable performance in these diverse and often challenging environments, making it ideal for monitoring adult, pediatric, and infant patients.
Can this device operate in wide temperature extremes?
Yes, the Masimo EMMA Capnograph is built for robust use in diverse clinical and challenging environments. The device is fully functional within the following specified operating temperature range:
- 23 to 122 °F
- -5 to 50 °C
This broad range ensures reliable performance, which is essential for pre-hospital, emergency medicine, and critical care settings. The rugged design also allows for a storage temperature range of -22 to 158 °F (-30 to 70 °C).
Does the EMMA Capnograph feature an intuitive interface?
Yes, the Masimo EMMA Capnograph is designed for simple and efficient operation.
- It features an intuitive interface and uses one-touch programming for straightforward control.
- It offers a rapid assessment capability, displaying $\text{EtCO}_2$ and respiration rate measurements, along with a real-time waveform, in just 15 seconds after warm-up.
- Operation is low maintenance as the device requires no routine calibration.
Is the $\text{EtCO}_2$ measurement range comprehensive?
Yes, the Masimo EMMA Capnograph provides a comprehensive End-Tidal Carbon Dioxide ($ ext{EtCO}_2$) measurement range suitable for monitoring adult, pediatric, and infant patients.
$\text{EtCO}_2$ Specifications:
- Measurement Range: 0 - 99 $\text{mmHg}$
- Accuracy: The device offers precise measurement across this range:
- 0 to 40 $\text{mmHg}$: $\pm$ 2 $\text{mmHg}$
- 41 to 99 $\text{mmHg}$: $\pm$ 6% of the reading
