Eagle Group MHC 3-Compartment-2 Size Bowls, Spec-Master Sfn Series Sinks

Yes, the Spec-Master SFN Series is specifically engineered for enhanced stability and maximum support required in demanding commercial environments. Its robust construction ensures longevity and high weight capacity.

Key features guaranteeing stability and support include:

• Heavy-Duty Legs: The unit is supported by 1 5/8” diameter stainless steel tubing.
• Optimal Placement: Legs are strategically positioned directly under the sink bowls to handle the maximum load.
• Reinforcement: Stability is fortified using stainless steel gussets welded to heavy-gauge stainless steel reinforcing corner plates.
• Rigidity: The entire assembly is crossbraced front-to-back for added structural rigidity.
• Adjustable Leveling: Fully adjustable stainless steel bullet feet allow the sink to be leveled perfectly, even on uneven floors.

Yes, the Spec-Master SFN Series sink assembly is supplied ready for installation and includes the necessary basket-type waste drains.

Key specifications for the included drains:

• Type: Basket-type
• Connection Size: 1 1/2 inch IPS (Iron Pipe Size)

This ensures the unit is ready to be plumbed into your commercial or industrial environment.

Yes, this Spec-Master SFN Series sink is configured to use standard commercial plumbing connections for efficient installation:

• Water Supply: Connections for both hot and cold lines require 1/2 inch IPS (Iron Pipe Size).
• Waste Drains: Each sink compartment includes a 1 1/2 inch IPS basket-type waste drain.
• Faucet Mounting: Faucet holes are pre-punched at 1 1/8” diameter on standard 8-inch centers, ensuring compatibility with most commercial faucets.

Yes, the Spec-Master SFN Series sink is designed to be plumbing ready for standard commercial faucet installation.

The sink unit includes the following essential specifications:

• Faucet Holes: Pre-punched 1 1/8” holes located on standard 8-inch centers.
• Water Supply Connections: Ready for 1/2 inch IPS hot and cold lines.

For drainage, the unit also includes 1 1/2 inch IPS basket-type waste drains.

Yes, this heavy-duty commercial sink is constructed using robust 14 gauge stainless steel throughout, which ensures exceptional durability and compliance for demanding industrial environments. Two different grades are strategically used:

• Type 304 Stainless Steel (14 gauge): Used for exterior components such as the drainboards, backsplash, and rolled rims. This grade provides superior corrosion resistance.
• Type 430 Stainless Steel (14 gauge): Used specifically for the construction of the three sink compartments. These bowls feature coved corners on a full 5/8 inch radius, constructed using state-of-the-art seamless welding for superior strength and hygiene.

Yes, the Spec-Master SFN Series sink is designed for flexibility, featuring a robust 18-inch drainboard that can be configured to best suit your operational layout.Key configuration details include:* Position Options: You can order the unit with the drainboard positioned on either the left end or the right end of the sink assembly.* Material: The drainboard is constructed from durable, heavy-duty 14 gauge Type 304 stainless steel, ensuring longevity in demanding commercial environments.

Yes, the sink compartments are specifically designed for superior hygiene and ease of maintenance in demanding environments.

• The compartments feature deep coving with a full 5/8 inch radius.
• This design, combined with state-of-the-art seamless welding techniques, eliminates sharp corners and hard-to-reach crevices where dirt or contaminants could accumulate.
• This construction ensures a smooth, non-porous surface, making rigorous sanitation quick and effective for commercial, medical, and laboratory settings.

Yes, the bull-nosed outside corners are specifically designed to enhance safety and cleanliness in commercial environments.

This feature provides safe, rounded edges that help prevent accidental injury in busy kitchens or facilities, while also contributing to better hygiene by eliminating sharp angles where dirt or debris might gather.

Yes, the Spec-Master SFN Series sink is engineered specifically for superior stability and maximum weight support required in heavy-duty commercial environments. The robust support system is designed using high-quality materials and strategic placement:

• Heavy-Duty Materials: The legs are constructed from 1 5/8” diameter stainless steel tubing.
• Strategic Placement: Legs are positioned directly beneath the sink bowls, optimizing load-bearing capacity and weight distribution.
• Reinforced Support: Stability is maximized by stainless steel gussets and heavy-gauge stainless steel reinforcing corner plates that are welded to the leg assembly.
• Enhanced Structure: The unit is crossbraced from front-to-back to minimize lateral movement.
• Adjustability: Fully adjustable stainless steel bullet feet ensure the unit can be perfectly leveled, even on uneven floors.

Yes, this Spec-Master SFN Series sink features three compartments with two distinct bowl sizes to provide maximum versatility for heavy-duty commercial or industrial use. The configuration is:

• Two standard compartments: 14 inches wide x 32 inches front-to-back.
• One large compartment: 20 inches wide x 30 inches front-to-back.

All sink compartments are constructed from robust 14 gauge Type 430 stainless steel. They feature coved corners (a full 5/8 inch radius) and utilize state-of-the-art seamless welding techniques for enhanced hygiene and structural integrity. The functional water level for these bowls is 14 inches.
