Allied Healthcare LSP Advantage Emergency Portable Suction Unit

The LSP Advantage unit provides a powerful and precise adjustable vacuum range suitable for critical emergency situations, ranging from gentle needs to severe airway obstructions. Its performance specifications are: * Adjustable Vacuum Range: The suction can be regulated from a minimum of 25 mm Hg up to a maximum of 550 mm Hg. * Vacuum Flow Rate: It delivers a robust flow rate of greater than 30 liters per minute (> 30 lpm) for rapid aspiration. *Note: The L190-GR configuration includes a Gauge and Regulator for precise, continuous adjustment across this entire range.

The LSP Advantage utilizes a powerful internal rechargeable lead-acid battery, ensuring reliable operation when AC or DC power is unavailable. Here are the key specifications:

• Continuous Runtime: Up to 75 minutes of continuous operation at the maximum vacuum setting (550 mm Hg).
• Recharge Time: The battery fully recharges in less than six hours via the internal AC charger or when connected to a DC source.

Yes, the Allied Healthcare LSP Advantage is designed with Tri-Power Operation for ultimate versatility and reliability in emergency situations. It ensures continuous use through three flexible power modalities:

• Internal Rechargeable Lead Acid Battery: Provides up to 75 minutes of continuous operation at the maximum 550 mm Hg suction setting. A full recharge takes less than six hours.
• Standard AC Power: Connects to a standard 115V, 50/60 Hz outlet using the internal charger.
• Emergency Vehicle/Docking Station: Operates via a 12V DC source, ideal for ambulances and air medical transport.

Crucially, the unit is engineered to run at full performance when plugged into an external AC or docking station source, even if the internal battery is completely depleted.

The unit is ready for immediate use as it does include an 800 cc disposable collection canister.

Here are the details for the included canister:

• Capacity: 800 cc
• Type: Disposable
• Inlet: Stem inlet

For applications requiring greater capacity, compatible 1500 ml disposable suction canisters are also available separately.

Yes, the LSP Advantage Portable Suction Unit features clear visual indicators to ensure you know the status of the internal rechargeable lead-acid battery:

• Charge Status Indicators: Dedicated lights clearly monitor and display the battery’s current charge and recharging status.
• Bad Battery Sensor: For enhanced safety, the unit includes a specialized sensor that uses 5 red LEDs to immediately alert the user if the battery is low or requires attention.

Crucially, the unit is designed for maximum reliability: it maintains full suction performance (up to 550 mm Hg) when connected to an external AC power source (115V) or an emergency vehicle docking station, even if the internal battery is completely depleted. A fully charged battery provides up to 75 minutes of continuous use on the high setting.

Yes, the LSP Advantage Emergency Portable Suction Unit provides a strong vacuum flow rate of greater than 30 lpm (liters per minute). This high flow rate is crucial for rapid and effective aspiration, making it suitable for managing critical airway obstructions in pre-hospital and transport settings.

The LSP Advantage Emergency Portable Suction Unit is often enhanced with key accessories that increase its functionality and portability in emergency transport settings:

• Docking Station Kit (#L200-010): Essential for secure mounting and continuous power/charging in emergency vehicles (like ambulances or helicopters), ensuring the unit is ready for immediate use.
• Portable Suction Unit Carrying Case (#L190-BAG): Provides a robust, protective solution for safe transport and easy carrying in the field.
• Disposable Hydrophobic/Bacteria Filters: Crucial for maintaining hygiene and protecting the pump mechanism by preventing fluids and biological contaminants from entering the unit.
• Larger Disposable Suction Canisters (e.g., 1500 ml): Available to supplement the included 800 cc canister, offering extended fluid collection capacity for longer or more intensive use.

The internal, rechargeable lead acid battery is designed for rapid turnover, requiring less than six hours for a complete charge. A key operational benefit is that the unit can maintain full operational performance, even when the battery is low or depleted, as long as it is connected to an external power source (AC outlet or 12V DC vehicle docking station). This ensures continuous readiness and reliability for emergency use.

Yes, the Allied Healthcare LSP Advantage Emergency Portable Suction Unit is engineered for reliable, continuous operation at full capacity while connected to an external power source.

This unit maintains full suction performance (up to 550 mm Hg vacuum power) even if the internal rechargeable battery is fully depleted or low. The unit achieves this performance when powered by:

• An emergency vehicle docking station (DC power).
• A standard AC outlet (115 volts, 50/60 Hz).

The Allied Healthcare LSP Advantage is designed for portability in emergency medical services (EMS), featuring a compact size and low weight for easy maneuverability in vehicles like ambulances or helicopters.

Its key physical specifications are:

• Unit Dimensions (L x W x H): 16.8” x 7.5” x 9.4” (42.7 cm x 19 cm x 24 cm)
• Unit Weight (Unit Only): 10.6 lb (4.8 kg)
