Yes, the Unico IP753 is built on a high-end Infinity Optics Platform for superior image clarity and versatility. It offers two options for objectives, depending on your application:

• Achromat Objectives (Standard): Provides excellent viewing quality and resolution.
• Plan Achromat Objectives (Premium): Offers superior flat-field correction, which is ideal for demanding applications like microscopy photography or precise measurements.

All configurations include the standard set of objective magnifications: 4X, 10X, 40XR, and 100XR.

Yes, the Unico IP753 offers Plan Achromat objectives as an upgrade option, utilizing the microscope’s high-end Infinity Optics system.

This versatility allows you to choose based on your imaging needs:

• Achromat Objectives (IP753 Model): The standard set.
• Plan Achromat Objectives (IP753PL Model): Recommended for professional work requiring superior image quality and excellent field flatness across the entire field of view, which is especially useful for detailed documentation.

All configurations come standard with 4X, 10X, 40XR, and 100XR Infinity Objectives.

Yes, the Unico IP753 is explicitly designed to support digital imaging and documentation.

This capability is facilitated by the Seidentopf Trinocular Head, which features a dedicated third port for mounting an external camera (camera sold separately).

Key features supporting digital capture include:

• 80/20 Beam Splitter: This feature efficiently divides the light path, allowing you to observe the specimen simultaneously through the eyepieces while capturing high-quality images or video via the camera port.
• Infinity Optics: The high-end infinity optics ensure the exceptional image clarity and flatness required for detailed digital analysis.

The Unico IP753 is built on a sturdy base, making it a stable instrument for professional laboratory use. The physical specifications are:

Yes, the Unico IP753 features Koehler type illumination. This system uses a built-in illuminator with a field diaphragm to provide bright, even, and consistent lighting across the entire field of view, which is essential for high-resolution imaging. Illumination intensity is easily adjustable via a variable intensity rheostat wheel.

Yes, the Unico IP753 features an ergonomic Seidentopf Trinocular Head designed for maximum user comfort during extended observation periods.

Key features that ensure adjustable viewing include:

• Interpupillary Distance: Easily adjustable from 55 mm to 75 mm to suit different users.
• Rotation: The head can be rotated a full 360°, which allows for collaborative viewing and flexible positioning.
• Diopter Adjustment: Available on one eye tube, providing customized focus correction for individual vision needs.

Additionally, the trinocular design incorporates an 80/20 beam splitter, which is ideal for simultaneously viewing specimens and capturing images with a mounted camera.

Yes, the Unico IP753 is designed for global compatibility, featuring variable voltage capabilities. It supports a wide range, ensuring flexibility in different laboratory environments:

• Variable Voltage: Operates from 110V-60Hz to 240V-50Hz.
• Safety & Compliance: All electrical components are UL & CSA Approved.
• Connection: The unit includes a three-wire grounded electric cord.

The Unico IP753 Advanced Trinocular Infinity Microscope ships complete with several essential items needed for long-term protection and operation:

• Dust Cover: For protecting the instrument when not in use.
• Blue Filter: Used to adjust the color temperature of the built-in illuminator.
• Two extra Fuses: Provides spares for maintaining the electrical system.
• Operation Manual: Detailed instructions for setup and usage.

Yes, the Unico IP753 utilizes a 4-Hole Reverse Nosepiece specifically designed to enhance operational efficiency and user comfort.

This reverse orientation offers several key advantages:

• Maximized Working Space: By positioning the objectives away from the stage, it greatly increases the working clearance above the large, heavy-duty mechanical stage (180mm x 150mm).
• Simplified Handling: The extra space allows for easier and quicker placement, adjustment, and removal of slides without obstruction.
• Objective Protection: The design helps protect the high-quality Infinity Objectives from accidental contact and potential damage during specimen changes.

Yes, the Unico IP753 Advanced Trinocular Infinity Microscope is specifically engineered with an ergonomic design to maximize comfort and reduce user fatigue during extended laboratory use.

Key features contributing to its usability include:

• Low Position Coaxial Coarse and Fine Focusing System: The controls are positioned low for natural hand placement and effortless adjustment. The system also includes a tension control feature on the coarse focus.
• Seidentopf Trinocular Head: This head is fully adjustable, offering 360° rotation, an interpupillary distance range of 55-75mm, and diopter adjustment, ensuring comfortable viewing for different users.
• Large Heavy Duty Mechanical Stage: The spacious 180mm x 150mm stage platform allows for comfortable and accurate specimen manipulation.
