Description

The TransMotion Medical TMM5 Mobile Surgical Stretcher-Chair includes a hand held operating pendant. It also includes a new head, body, and leg mattress pad.

Warranty: 90 Days - Parts and Labor.

Note: Head extension and extension pad are sold separately.

The TMM5 series provides superior surgeon access with the versatile articulating head piece, tapered back section, and lots of leg clearance while in stretcher position. Thick memory foam cushions offer exceptional patient comfort, while powered positioning provides for safe patient handling.

Utilizing a hand-held pendant allows for easy push-button patient positioning for both back and leg sections, as well as a low/high height adjustment. All TransMotion Medical Stretcher-Chairs come standard with the manual quick release back should urgent patient care be required.

With the TMM5, you no longer have to transfer the patient from stretcher to surgical table and back. While the patient is in pre-op, they enter the unit in chair position, staff uses the pendant to press a button to convert the chair to stretcher position, roll the patient into surgery for the procedure, then uses the pendant to press a button to set the stretcher to the preferred surgeon height, then roll the patient to post-op to recover in a comfortable reclining position. The TMM5 eliminates the need for patient transfer and manual positioning during their entire stay, thereby reducing patient fall and staff injury risk. Eliminating transfers also provides greater patient throughput.

Features

TransMotion Medical TMM5 Mobile Surgical Stretcher-Chair Features

  • 3" longer wheel base.
  • Self storing push bars fold out of the way when not in use.
  • Manual quick release back.
  • Cushioned, chrome side rails protect the patient during transport and procedures, then swing down and tuck away for easy patient side ingress and egress.
  • Brakes located in middle.
  • No foot rest.
  • Easy mobility steer casters with braking system.
  • All-metal surfaces for a long, durable life.
  • Space-saving footprint.

Specifications

TransMotion Medical TMM5 Mobile Surgical Stretcher-Chair Specifications

  • Seat Height: 21 - 33" (53 - 83.8 cm).
  • Cushion Height: 3.75" (9.5 cm).
  • Patient Seat Width: 24" (61 cm).
  • Patient Surface Length: 75" (190.5 cm).
  • Overall Width: 30" (76 cm).
  • Overall Chair Height: 56 - 64" (142 - 163 cm).
  • Max Patient Weight: 500 lb (227 kg).
  • Backrest Articulation: 0 - 75 degrees.
  • Trendelenburg: 20° standard.
  • Reverse Trendelenburg: 5°.
    • Note: If "R" (upper rails) are added to an "X" option it redeuces Trendelenburg by 10°.
  • Side Rails:
    • Height: 13" (33 cm).
    • Length: 26" (66 cm).
  • Charging System:
    • Input Volts: 100 - 240 vac.
    • Frequency: 50/60 Hz.
    • Output: + 24 v DC 1.5 a.
  • Chair Weight: 200 - 250 lb (90 - 113 kg).

Models

TransMotion Medical TMM5 Mobile Surgical Stretcher-Chair Models

  • #TMM5-X: with Trendelenburg Seat Tilt.
  • #TMM5-XTB: with Trendelenburg Seat Tilt, Triple Tower Column, and Battery (Rechargeable).
  • #TMM5-XWTB: Wide Version with Trendelenburg Seat Tilt, Triple Tower Column, and Battery (Rechargeable).
  • #TMM5-XT: with Trendelenburg Seat Tilt and Triple Tower Column.
  • #TMM5-XTFB: with Trendelenburg Seat Tilt, Triple Tower Column, Folding Foot Rest, and Battery (Rechargeable).
  • #TMM5-XB: with Trendelenburg Seat Tilt and Battery (Rechargeable).
  • #TMM5-119: with Trendelenburg Seat Tilt, Headrest, and Battery (Rechargeable).
  • #TMM5-WTB: Wide Version with Triple Tower Column and Battery (Rechargeable).
