- Weight: 475.0 lb
- At the touch of a button, this bed can be placed in a Trendelenburg position, raised, or lowered to achieve maximum positioning
- Lock-Rite slide-off foot section glides off with ease for quick and easy breakdown and a visual indicator will allow you to ensure it is locked
- Three-position side rails
- Automatic pelvic tilt
-
Learn more:
-
MFR:
Stryker
Ships from MFI Medical
-
MPN: LD304
- Phone: (269) 385-2600
Frequently asked questions
What motorized positioning functions are included?
The Stryker LD304 Birthing Bed is equipped with four distinct motor functions that provide precise and comprehensive positioning capabilities:
- Head/Backrest: Allows adjustment of the backrest angle from 0° up to 70°.
- Bed Height: Adjusts the bed’s litter height between a low of 17.5 in (44 cm) and a high of 35.5 in (90 cm).
- Foot Section: Enables independent foot position adjustments, complemented by length-adjustable footrests for infinite leg positioning.
- Trendelenburg: Achievable instantly via a single button press, positioning up to a maximum of 8°.
These functions are controlled using integrated in-rail motion controls which feature a safety lockout. The bed also includes an essential automatic 4° pelvic tilt function, CPR release, and manual backup controls.
What superior safety and control features are included?
The Stryker LD304 Birthing Bed includes several advanced features focused on patient safety, high mobility, and precise caregiver control:
- Secure Mobility and Braking: The bed utilizes 6-inch Omni Surface casters for smooth movement, secured by a reliable four-wheel steel-ring brake system. The centralized activation pedal also provides locking caster steering.
- Intuitive Positioning Controls: Controls for the four motorized functions (head, bed height, foot, and Trendelenburg) are integrated into the three-position side rails, which also feature a lockout mechanism to prevent accidental adjustments.
- Caregiver Ergonomics: The Lock-Rite slide-off foot section is designed to be lightweight and easy to remove, significantly aiding proper body mechanics and helping to mitigate caregiver back strain during bed breakdown.
- Emergency Functions: Safety features include an essential CPR release mechanism and an integrated manual backup system, ensuring reliability during emergencies or power interruptions.
- High Support Capacity: The robust structure is engineered to accommodate patients with a maximum bed lift capacity of 500 lb.
Does the foot section simplify caregiver tasks?
Yes, the Lock-Rite slide-off foot section is lightweight and self-standing, designed to prevent back strain and injury for caregivers. It can be easily removed for quick breakdown.
Does the bed have a manual backup for power outages?
Yes, the Stryker LD304 Birthing Bed includes a manual backup feature, ensuring continued operation even in the event of a power outage.
Does the design specifically reduce caregiver physical strain?
Yes, the Stryker LD304 is engineered with a focus on ergonomics to actively minimize caregiver injury and back strain. Key features that assist in this include:
- Motorized adjustments: Reduces the need for manual lifting and positioning.
- Efficient breakdown: The Lock-Rite slide-off foot section is lightweight and self-standing, allowing for quick transitions without excessive physical effort.
- Optimized height range: The bed adjusts from 17.5” to 35.5”, ensuring caregivers can work at a height that maintains proper posture.
Does the bed include useful integrated clinical accessories?
Yes, the Stryker LD304 comes fully equipped to support clinical requirements during labor and delivery. Included features are:
- Permanent folding three-stage IV pole: Offers flexible height adjustments for fluid administration.
- Plastic fluid basin: Essential for managing fluids during the delivery process.
- Under-bed night light: Provides soft illumination to assist caregivers during nighttime operations without disturbing the patient.
- Wood headboard: Adds a warmer, more patient-friendly aesthetic to the clinical environment.
What is the maximum patient weight capacity?
The Stryker LD304 Birthing Bed offers a generous maximum overall patient weight capacity of 500 lb.
Specific weight capacities are also provided for the articulating sections:
- Head Section: 250 lb
- Foot Section: 300 lb
Does the bed include a fluid basin?
Yes, the Stryker LD304 Birthing Bed includes a plastic fluid basin as part of its design, which is beneficial for maintaining hygiene and managing fluids during labor and delivery.
Are high-quality casters included?
Yes, the Stryker LD304 Birthing Bed is designed for superior mobility and safety, featuring robust, high-quality components:
- 6-inch (15 cm) Omni Surface Casters: These large casters ensure smooth movement throughout the facility and include wheel covers, along with locking steering capabilities for precise control.
- Secure Braking System: The bed utilizes a robust four-wheel steel-ring brake system. This system is activated via a centrally-located pedal, guaranteeing secure, stable positioning when needed.
Is a high-quality mattress included?
Yes, the Certified Refurbished Stryker LD304 Birthing Bed comes standard with a high-quality mattress system designed for optimal patient support.
This includes:
- A new 6-inch Hospital-Grade Memory Foam Mattress, ensuring superior comfort and hygiene.
- The underlying support surface is layered, featuring different thicknesses for the articulating sections:
- Head/Seat Section: 5 inches (13 cm) thick.
- Foot Section: 3 inches (8 cm) thick.
