Seiler Alpha Air 6 Dental Microscope

The Seiler Alpha Air 6 Dental Microscope includes user guide, choice of mounting option (floor, ceiling, wall, high wall, or tabletop), LED illumination system, pantographic arm, optic pod, and binocular head.

Warranty: Lifetime - Optics and Mechanics.

The Seiler Alpha Air 6 Dental Microscope is a high quality Dental microscope with six levels of magnification, apochromatic lenses for superior optics, standard 150,000 LUX LED illumination and a specially engineered Gas Piston Pantographic Arm for superior maneuverability. This multi-purpose microscope uses high quality German optics and the brightest standard LED light source on the market. The Air 6 has a compact design that allows it to function in any environment, no matter the size constraints.

Seiler Alpha Air 6 Dental Microscope Features

• Six-step Turret magnification system.
• True Coaxial illumination.
• Over 50,000 hours of bulb life.
• Composite and Red Free Filter standard.
• USB and 12V DC power support directly on optic pod.
• Five Mounting Options Available: Floor, wall, high wall, ceiling, and tabletop.
• Two Head Options Available: Fixed 45° Head or Inclinable 0 - 220° Binocular Head.

Seiler Alpha Air 6 Dental Microscope Configurations

• #AA6-100-LED: Fixed Head; Floor Stand.
• #AA6-200-LED: Fixed Head; Wall Mount.
• #AA6-300-LED: Fixed Head; High Wall Mount.
• #AA6-400-LED: Fixed Head; Ceiling Mount.
• #AA6-500-LED: Fixed Head; Tabletop Mount.
• #AA6-100-LED220: Inclinable Head; Floor Stand.
• #AA6-200-LED220: Inclinable Head; Wall Mount.
• #AA6-300-LED220: Inclinable Head; High Wall Mount.
• #AA6-400-LED220: Inclinable Head; Ceiling Mount.
• #AA6-500-LED220: Inclinable Head; Tabletop Mount.

Seiler Alpha Air 6 Dental Microscope Specifications

• Minimum Possible Working Distance: 6.89" (175 mm).
• Maximum Possible Working Distance: 15.75" (400 mm).
• Microfocus Vertical Adjustment Range: 13 mm.
• Microscope Weight (Floor Model): 162 lb (73.48 kg).
• Objective Lens: Æ’ = 250 mm.
• Eyepieces: 10x.
• Diopter Setting: -6 to +6.
• Field of Vision: 10 to 66 mm.
• Magnification Levels: 2.8x, 4.1x, 5.3x, 8.7x, 11x, 17x.
• Power Supply: Mains Power 96 - 264 VAC; 47 - 63 Hz.
• Auxiliary Power Jack: 12 VDC .5 A maximum.
• Fuses: (2) 1.5 A 250 VC, type GMA.
• USB Jack: 5 VDC; 0.5 AMP.
• Power Cable: IEC 320/C13 Hospital Grade.
• Light Source Type: LED (Light Emitting Diode).
• Color Temperature: 5700 CCT.
• LED Life: >50,000 Hours.
• Typical Illuminance: 120,000 - 150,000 LUX.
• Brightness Control: Digital - 1024 Resolution.
• Mode of Operation: On/Off//Standby (Continuous).
• Input Voltage: 96 - 264 VAC.
• Rated Power: 80 watts.
• Water Resistance: IPXO.
• Operating Temperature:40°F to 100°F (4.4°C to 37.8°C).
• Operating Relative Humidity: 30 to 75%.
• Air Pressure: 700 HPA to 1060 HPA.
• Storage Temperature: 20°F to 122°F (-6.7° to 50°C).
• Relative Humidity: 0 to 100% (Non-Condensing).

Seiler Alpha Air 6 Dental Microscope Literature

Seiler Dental Catalog

Seiler Dental Alpha Air Series Brochure

Seiler Alpha Air 6 Dental Microscope User Manual
