- Condition: Factory New
- Warranty: 90 Days
- Weight: 0.33 lb
- Symbol Barcode Reader ($100 Minimum Order Requirement or customer will be charged $30 min order fee)
-
Learn more:
- MFR: Schiller Ships from Manufacturer
- MPN: SR20001R-UR
- Phone: (786) 845-0620
Frequently asked questions
What interfaces does the LS-2208 support?
The Schiller LS-2208 offers broad connectivity via a plug-and-play universal cable, which streamlines setup and maximizes compatibility with various computing environments. This eliminates the need for complex training or integration.
It supports the following major interfaces:
- USB
- RS232
- Keyboard Wedge
- IBM 468x/9x
Is the LS-2208 scanner drop resistant?
Yes, the Schiller LS-2208 is designed for robust performance in high-volume, demanding environments. Its key durability feature is its ability to withstand:
- Repeated 5-foot (1.5 m) drops to concrete while continuing to function normally.
This construction minimizes downtime and ensures reliability throughout continuous daily use.
What is the operating and storage temperature range?
The Schiller LS-2208 is engineered for use in demanding medical environments with specific environmental tolerances:
- Operating Temperature: 32° to 122° F (0° to 50° C)
- Storage Temperature: -40° to 158° F (-40° to 70° C)
The device is also tolerant of humidity levels ranging from 5% to 95% non-condensing.
How lightweight is the Schiller LS-2208 Barcode Scanner?
The Schiller LS-2208 Barcode Scanner is highly lightweight, weighing only 0.33 lb (150 g).
This deliberate design is intended to reduce user fatigue, ensuring the device remains comfortable and easy to handle during continuous, all-day operation in demanding medical environments.
What voltage does the LS-2208 require?
The Schiller LS-2208 Barcode Scanner operates using low-voltage DC power. The required specifications are:
- Input Voltage: 5 volts (± 10%)
- Current Draw (Typical): 130 mA
- Current Draw (Maximum): 175 mA
What is the scan speed?
The Schiller LS-2208 provides a high-performance scan speed of 100 scans per second. This rapid speed, coupled with its bi-directional 1-D laser, ensures accurate first-time capture, improving efficiency for continuous, high-volume use.
Is the Schiller LS-2208 a bi-directional scanner?
Yes, the Schiller LS-2208 is a bi-directional scanner.
Is this scanner ideal for continuous clinical use?
Yes, the Schiller LS-2208 is specifically engineered for high-volume, continuous daily operation, making it ideal for demanding medical environments. Its lightweight design and high-performance scanning capabilities ensure productivity throughout long shifts.The scanner is perfectly suited for:
- Scanning Patient Charts: Its primary design focus is efficient and reliable data capture of patient records.
- Clinical Data Entry: Excellent for hospital workstations and point-of-care applications.
- Active Environments: The robust construction is certified to function normally after repeated 5 ft (1.5 m) drops to concrete, making it suitable for active clinical settings.
Does this scanner offer advanced data formatting?
Yes, the Schiller LS-2208 Barcode Scanner is equipped with Advanced Data Formatting.
This valuable feature allows you to modify the scanned data before it is transmitted to the host computer. The main benefit is that it can eliminate or minimize the need for costly software modifications on the host system, greatly streamlining integration and deployment.
What kind of laser is used?
The Schiller LS-2208 Barcode Scanner uses a 650 nm Visible Laser Diode as its light source for accurate 1-D barcode scanning.
