OakWorks PT 400 Table

The OakWorks PT 400 Table is designed for clinical versatility, offering multiple width options and a substantial electric height range for optimal patient access and ergonomic use. The robust stiff twin beam construction ensures stability throughout all adjustments.

Key Dimensions and Range

• Available Widths: You can select a top section width of either 29 inches (74 cm) or 31 inches (79 cm).
• Electric Height Range: The powered motor allows for height adjustment from a low entry point of 17 inches (43 cm) up to 35 inches (89 cm).
• Total Length: The overall treatment surface length is 73 inches (185 cm).
• Weight Capacity: The table safely supports a maximum patient weight of 550 lb (250 kg).

Yes, the OakWorks PT 400 Table is built with a stiff twin beam construction to ensure robust stability, providing a high weight capacity.

• Weight Capacity: 550 lb (250 kg)

The OakWorks PT 400 Table offers a wide electric height adjustment range to ensure optimal ergonomic positioning for therapists and easy access for patients.

• Height Range: The table adjusts from a low of 17 inches (43 cm) up to a high of 35 inches (89 cm).
• Stability and Power: This movement is powered by an ETL listed motor, and the stiff twin beam construction ensures uniform stability across the entire range, maintaining its substantial 550 lb (250 kg) weight capacity.
• Control: Height adjustments are easily managed using the standard multi-function foot control.

Yes, the OakWorks PT 400 Table is specifically designed for high versatility and is capable of achieving the Trendelenburg position.

This crucial functionality is supported by the table’s advanced electric articulation features, which allow it to smoothly transition between a treatment chair and a multi-position table:

• Electric Center Break Motion: Articulates from 0° up to 45°.
• Electric Height Range: Adjusts from a low access point of 17 inches (43 cm) up to 35 inches (89 cm).

Stability during these complex positional changes is guaranteed by the robust stiff twin beam construction.

Yes, the multi-function foot control comes standard with the OakWorks PT 400 Table, ensuring convenient, hands-free operation of the powered features.This control is used to adjust two primary movements:

• Electric Height Adjustment: Seamlessly moves the treatment surface through its full range, from 17” up to 35” (43 cm to 89 cm).
• Electric Center Break Motion: Controls the table top’s tilt from 0° to 45°, allowing for precise patient positioning, including the Trendelenburg position.

The OakWorks PT 400 Table can be customized with several beneficial optional accessories to enhance mobility and control. Please note that these accessories must be requested and ordered at the time of purchase.

Available Optional Accessories:

• Locking Twin Casters: These casters allow for easy movement and repositioning of the table within your facility, and they include a locking mechanism for stability during patient treatment.
• Hand Control: Provides an alternative, handheld remote for convenient and precise electric control over the table’s height and positioning features.
• Second Foot Control: Offers an additional multi-function foot control, allowing practitioners to easily manage the table’s electric adjustments from various positions around the patient.
• Non-USA Electric System: This system is required if the table is intended for use in regions outside of the United States.

Yes, the OakWorks PT 400 Table is engineered for exceptional versatility, allowing it to function effectively as both a traditional treatment table and an upright chair. It also supports specialized medical positioning, including the crucial Trendelenburg capability.

This high degree of versatility is achieved through its numerous adjustment mechanisms:

• Dual Functionality: Easily converts between a treatment table and a physical therapy chair configuration.
• Electric Height Range: Height is electrically adjustable from 17 inches up to 35 inches (43 cm to 89 cm).
• Electric Center Break: Powered articulation ranges from 0° to 45°.
• Manual Backrest: Features manual lift-assist motion, adjustable from 0° to 85°.
• Manual Head Section: The head section offers an extensive adjustment range, from 47° down to -92°.

Yes, the OakWorks PT 400 Table utilizes 1.75” (4 cm) Firm Response Foam padding. This specialized feature is integrated to provide superior patient comfort and ergonomic support during various physical therapy applications.

Furthermore, the padding is covered with premium, PVC-free TerraTouch fabric, ensuring durability and ease of cleaning.

The OakWorks PT 400 Table is upholstered with premium, PVC-free TerraTouch fabric. This material ensures both durability and comfort for patients during treatments.

The OakWorks PT 400 features a highly flexible manual head section designed for precise patient positioning and comfort.

• Adjustment Range: It manually adjusts through a very wide range, from 47° (upward tilt) to -92° (downward tilt), providing exceptional versatility for various physical therapy treatments.
• Dimensions & Comfort: The head section measures 11 inches (28 cm) long and includes a face cutout for comfort during prone positioning.
• Padding: It is cushioned with durable 1.75-inch Firm Response Foam and upholstered in premium, PVC-free TerraTouch fabric.
