Condition:
Factory New
-
Country of Origin: USA
-
Warranty:
- Weight: 475.0 lb
- Large adjustable height range
- 56 inches of metal free imaging space
- Cost effective 4 movement table
- 500 lb patient weight capacity
-
Learn more:
-
MFR:
OakWorks
Ships from Manufacturer
-
MPN: 81802
- Phone: (717) 759-3146
+Shipping
Shop with Confidence
Sales Tax Exemption
+Dedicated Account Managers
Frequently asked questions
Does this table offer generous metal-free imaging space?
Yes, the OakWorks CFPM401 is specifically engineered for imaging and pain management, offering a generous, unobstructed imaging field.
It provides 56 inches of continuous metal-free space on the table top, which is essential for C-arm fluoroscopy and high-precision radiographic procedures. This capability is made possible by:
- The table’s carbon fiber construction for superior radiolucency.
- The use of a 2-inch (5 cm) thick Radiolucent Comfort Foam pad that minimizes interference while maximizing patient comfort.
What is the adjustable height range?
The OakWorks CFPM401 features a wide electric height adjustment range, which is essential for achieving optimal physician ergonomics and ensuring safe patient transfers.
-
Height Range (Electric): 26 inches (66 cm) to 44 inches (112 cm).
-
Note: This range is measured for the table structure and does not include the additional height provided by the 2-inch (5 cm) Radiolucent Comfort Foam table top pad.
Is the Trendelenburg tilt range versatile?
Yes, the OakWorks CFPM401 features a precise, electrically controlled Trendelenburg tilt that offers versatility crucial for patient positioning during imaging and pain management procedures.The available range is:
- Trendelenburg (Head Down): Up to +15°
- Reverse Trendelenburg (Head Up): Down to -11°
This tilt is one of the table’s four electric movements, allowing for high precision positioning and ease of use via the standard multi-function hand control.
Does it feature extensive longitudinal and lateral travel?
Yes, the OakWorks CFPM401 is designed for highly precise positioning, featuring four electric movements including substantial longitudinal and lateral travel. This versatility is essential for maintaining optimal C-arm access during complex imaging and pain management procedures.
The specific travel ranges are:
- Electric Longitudinal Travel: 10 inches (25 cm) of movement along the length of the table.
- Electric Lateral Travel: 8 inches (20 cm) of total side-to-side travel, providing a precise shift of ±4 inches (±10 cm) from the center.
This movement capability, combined with the 56 inches of metal-free imaging space, ensures superior access and positioning control.
Does the table have a high weight capacity?
The OakWorks CFPM401 is engineered for robust support and exceptional stability during imaging and pain management procedures.
- Patient Weight Capacity: The table offers a maximum safe working load of 500 lb (227 kg).
- Rigid Construction: This substantial capacity is supported by a rigid lifting column that ensures stability and minimizes deflection, which is crucial for high-precision C-arm imaging.
Is a high-quality radiolucent comfort pad included?
Yes, the CFPM401 table comes standard with a complete, high-quality padding system optimized for both patient comfort and superior imaging:
- 2-inch (5 cm) Radiolucent Comfort Foam Pad: This primary pad provides essential cushioning while ensuring clear visibility for fluoroscopic and radiographic procedures, thanks to its radiolucent properties.
- Premium Upholstery: The pad is covered in TerraTouch™ Medical Grade Fabric. This material is premium, PVC-free, and ISO 10993 Certified for safe patient contact and easy cleaning.
- Integrated Headrest Components: The table also includes an integrated headrest system with a Crescent face rest pad for comfort during prone positioning.
Does the table include high-quality locking casters?
Yes, the OakWorks CFPM401 is engineered for secure positioning and easy mobility. The table’s caster configuration is as follows:
- Standard Casters: The table includes 4-inch (10 cm) locking casters as a standard feature. These provide essential stability by locking the table securely during imaging procedures while allowing for safe repositioning when unlocked.
- Optional Upgrade: For enhanced maneuverability, the table can be optionally configured with 5-inch Fallshaw Casters.
Does the tabletop feature premium medical-grade fabric?
Yes, the OakWorks CFPM401 includes a 2-inch (5 cm) Radiolucent Comfort Foam table top pad covered in premium, medical-grade upholstery.
Key features of the upholstery include:
- It is made from PVC-free TerraTouch™ Medical Grade Fabric.
- The material is ISO 10993 Certified for biocompatibility, ensuring patient safety in clinical environments.
Is a comfortable integrated headrest included?
Yes, the OakWorks CFPM401 is designed with patient comfort as a priority and includes several integrated features as standard:
- Integrated Headrest Top: Provides stable and secure positioning for the patient during both imaging and pain management procedures.
- Crescent Face Rest Pad: This specialized pad is included with the integrated headrest to maximize comfort, especially when the patient is in a prone position.
- Premium Comfort Padding: The entire tabletop uses a 2-inch (5 cm) thick Radiolucent Comfort Foam pad for optimal cushioning.
- Medical Grade Fabric: The pad is covered in high-quality, PVC-free TerraTouch™ Medical Grade Fabric, which is certified to ISO 10993 standards for safety and durability.
Is a multi-function hand control standard?
Yes, the multi-function hand control is included as the standard component for the OakWorks CFPM401 table. This control is used to manage all four precision electric movements:
- Electric Height Range (26 inches to 44 inches)
- Electric Trendelenburg Tilt (+15°/-11°)
- Electric Longitudinal Travel (10 inches)
- Electric Lateral Travel (8 inches)
Alternatively, a Multi-Function Foot Control is available as an optional upgrade for hands-free operation.
