Condition:
-
Country of Origin: USA
-
Warranty:
- Weight: 475.0 lb
- 56 inches of metal free imaging space
- Large adjustable height range
- 500 lb patient weight capacity
- Pewter fabric color
-
Learn more:
-
MFR:
OakWorks
Ships from Manufacturer
-
MPN: 81803
- Phone: (717) 759-3146
Frequently asked questions
Is the upholstery material ISO certified?
Yes, the OakWorks CFPM300 utilizes premium, PVC-free TerraTouch Medical Grade Fabric.
This high-quality material is designed for clinical use and safety, confirmed by its ISO 10993 Certification. The standard color provided is Pewter.
For enhanced patient comfort during procedures, the table also features a 2-inch (5 cm) thick Radiolucent Comfort Foam pad.
Is the multi-function hand control included?
Yes, the multi-function hand control is included as the standard method of operation for the OakWorks CFPM300 table.
This control provides precise, electric management over the table’s three key positioning movements:
- Electric Height Adjustment: Easily sets the working height between 26 inches (66 cm) and 43 inches (109 cm) (measured without the pad), ensuring safe patient transfer and optimal clinician access.
- Electric Trendelenburg Tilt: Provides controlled longitudinal tilting within a range of +15° (head down) to -11° (head up).
- Electric Lateral Tilt: Offers side-to-side tilting up to ±15°.
A Multi-Function Foot Control is also available as an optional upgrade for hands-free operation.
What high-quality components are included?
The standard configuration of the OakWorks CFPM300 includes several key components designed for safety, operational efficiency, and clinical compliance:
- 2-Inch Radiolucent Comfort Foam Pad: Ensures high-quality, unobstructed imaging and patient comfort across the large carbon fiber top.
- Integrated Headrest Assembly: Features a built-in headrest and includes a Crescent face rest pad for optimal patient positioning.
- Premium TerraTouch Fabric: The table is upholstered in PVC-free, medical-grade TerraTouch material (ISO 10993 Certified) in Pewter.
- Multi-function Hand Control: This is the standard interface for precisely managing the three electric movements (Height, Trendelenburg Tilt, and Lateral Tilt).
- Safety and Mobility: The table includes 4-inch locking casters for stability and two patient straps for safely securing the patient during procedures.
What is the patient weight capacity?
The OakWorks CFPM300 table offers a robust patient weight capacity of 500 lb (227 kg). This high capacity is supported by the table’s rigid lifting column design, which ensures rock-solid stability during imaging and pain management procedures.
Does this table offer excellent metal-free imaging space?
Yes, the OakWorks CFPM300 is specifically designed for procedures requiring high imaging compatibility.
It features a Carbon Fiber Top that provides a remarkable 56 inches of uninterrupted, metal-free imaging space. This generous length ensures excellent radiolucency and unobstructed fluoroscopy, which is crucial for clear diagnostics and precise positioning during pain management and other imaging procedures.
What is the electric height adjustment range?
The OakWorks CFPM300 features three essential electric movements to ensure precise patient positioning and ergonomic access for medical staff. These adjustments are managed using the standard multi-function hand control.
Key movement ranges are:
- Electric Height Range: The table height adjusts significantly from a low of 26 inches (66 cm) up to a high of 43 inches (109 cm), measured without the pad.
- Electric Trendelenburg Tilt: Allows for specific longitudinal tilting, ranging from +15
° to -11
°. - Electric Lateral Tilt: Provides symmetrical side-to-side tilting up to ±15
°.
What are the maximum Trendelenburg and lateral tilt ranges?
The OakWorks CFPM300 provides precise electronic positioning with the following maximum tilt capabilities:
- Electric Lateral Tilt (Side-to-Side):
- The table offers a range of **
15
** in either direction (±15
).
- Electric Trendelenburg Tilt (Longitudinal):
- The maximum upward tilt (Trendelenburg) is **+15
**, and the maximum reverse tilt is **-11
**.
These three electric movements (including height adjustment) are controlled via the standard multi-function hand control.
Does the table feature an integrated headrest?
Yes, the OakWorks CFPM300 is engineered with an integrated headrest as a standard component of its carbon fiber top, ensuring precise and stable patient positioning for imaging and pain management procedures. This integration helps maximize the available 56 inches of metal-free imaging space.
Key features related to the integrated headrest system include:
- Included Pad: A 2-inch (5 cm) Radiolucent Comfort Foam table top pad provides cushioning without obstructing C-Arm access.
- Crescent Face Rest: A specialized Crescent face rest pad is included for enhanced patient comfort.
- High-Quality Fabric: The table is upholstered in Pewter-colored, premium, PVC-free TerraTouch Medical Grade Fabric, which is ISO 10993 Certified.
Is the imaging table highly certified for safety?
Yes, the OakWorks CFPM300 table is highly certified, ensuring it meets strict international and US regulatory standards for medical devices. The table holds the following critical safety and regulatory listings:
- CE marked
- cETLus approved
- CB Certificate
- FDA Listed
Additionally, the premium, PVC-free TerraTouch Medical Grade Fabric upholstery is ISO 10993 Certified, confirming its biocompatibility and safety for patient contact.
