Condition:
-
Country of Origin: USA
-
Warranty:
- Weight: 475.0 lb
- Rectangular top
- Large height range table 25 "- 43"
- 52" (133 cm) of metal free imaging space
- 500 lb patient weight capacity
-
Learn more:
-
MFR:
OakWorks
Ships from Manufacturer
-
MPN: 84524
- Phone: (717) 759-3146
Frequently asked questions
What is included with the imaging table?
The OakWorks CFPM200 is shipped complete with the essential accessories needed for immediate clinical operation. The standard included components are:
- 2 inch (5 cm) Radiolucent Comfort Foam Table Top Pad: Ensures patient comfort while maintaining crucial radiolucency for imaging.
- 4 inch (10 cm) Locking Casters: Provides mobility for placement and locks securely to ensure rock-solid stability during procedures.
- Two Patient Straps: Included for secure patient positioning.
Note that the table’s standard functionality—including electric height adjustments (25” to 43”) and electric lateral tilt (±15°)—is operated via the standard hand control.
Does the OakWorks CFPM200 table feature medical-grade fabric?
Yes, the OakWorks CFPM200 table uses Premium, PVC-free TerraTouch™ Medical Grade Fabric. This fabric is also ISO 10993 Certified, ensuring patient comfort and safety during procedures.
Does the CFPM200 have safety certifications?
Yes, the OakWorks CFPM200 table is extensively certified to ensure the highest standards of medical device safety and regulatory compliance.
This imaging and pain management table holds significant regulatory approvals, including:
- FDA listed
- CE marked
- cETLus approved
- CB Certificate
Additionally, the patient surface uses high-quality materials for safety. The upholstery features Premium, PVC-free TerraTouch™ Medical Grade Fabric, which is independently ISO 10993 Certified for biocompatibility and safe patient contact.
What is the versatile electric height adjustment range?
The OakWorks CFPM200 features a highly rigid electric lifting column, ensuring rock-solid stability across its entire range while supporting both safe patient transfers and comfortable physician positioning.
Key details for the height adjustment are:
- Electric Height Range (without pad): The surface adjusts from a minimum of 25 inches (64 cm) to a maximum of 43 inches (109 cm).
- This range allows for significant flexibility in procedural setup.
- Note that the standard 2-inch (5 cm) thick Radiolucent Comfort Foam pad adds to the overall patient support surface height.
Does the table feature precise electric lateral tilt?
Yes, the OakWorks CFPM200 is equipped with precise electric lateral tilt functionality, which is essential for accurate patient positioning during pain management and imaging procedures. This feature is standard.
Key details regarding the tilt feature:
- Tilt Range: The table offers a smooth adjustment up to ±15 degrees.
- Control Mechanism: This movement, along with the electric height adjustment, is managed via the standard all-functions Hand Control. A Multi-Function Foot Control is available as an optional configuration.
Where is the OakWorks CFPM200 table best used?
The OakWorks CFPM200 Imaging-Pain Management Table is ideally suited for use in hospitals, imaging centers, and pain management clinics. Its design supports a variety of medical imaging and pain management procedures in these environments.
How much does the stable imaging table weigh?
The OakWorks CFPM200 table weighs 475 lb (216 kg). This substantial weight contributes to its high stability, ensured by a very rigid lifting column, which is essential for minimizing movement during imaging and procedures.
What is the warranty offered for the OakWorks CFPM200 imaging table?
The OakWorks CFPM200 comes with a 4-year warranty on parts and a 3-year warranty on labor, providing peace of mind.
How much metal-free imaging space is provided?
The OakWorks CFPM200 is specifically engineered for fluoroscopic clarity, featuring a highly rigid carbon fiber rectangular top.
This design provides an exceptional and continuous 52 inches (133 cm) of unobstructed, metal-free space, ensuring optimal C-arm access during advanced diagnostic and pain management procedures.
Key specifications related to the imaging surface include:
- Table Top Material: Fully radiolucent Carbon Fiber.
- Top Dimensions: 22 in x 84 in (56 cm x 214 cm).
- Standard Padding: Includes a 2-inch (5 cm) thick Radiolucent Comfort Foam top pad for enhanced patient comfort without compromising image quality.
Does the table offer a high weight capacity?
Yes, the OakWorks CFPM200 table is designed to safely accommodate a wide range of patients with its impressive 500 lb (227 kg) weight capacity.
