- Condition: Factory New
- Country of Origin: Switzerland
- Warranty: 2 Years
- Weight: 17.65 lb
- Ideally suited for Spirometry, DLCO, and Provocation testing
- Helps determine lung volumes via multi-breath nitrogen washout
- Automated user guidance and test quality is based on 2019 and 2005 ATS/ERS standards
- Easily export of pdf files and raw data
-
Learn more:
- MFR: ndd Medical Ships from MFI Medical
- MPN: 3100-1
- Phone: (978) 470-0923
Frequently asked questions
How does the EasyOne Pro LAB ensure accuracy?
The EasyOne Pro LAB ensures exceptionally accurate and reliable results by incorporating ndd Medical’s proprietary technology and adhering to stringent industry standards:
- TrueFlow and TrueCheck Technology: These systems are specifically engineered to provide precise measurements and actively eliminate common sources of error that can compromise standard pulmonary function tests.
- Standards Compliance: The device features automated user guidance and test quality adherence based on the official 2019 and 2005 ATS/ERS standards.
- Measurement Reliability: This accuracy is crucial for comprehensive testing, particularly when determining the Lung Clearance Index (LCI) via the Multiple Breath Nitrogen Washout (MBW) technique.
What makes the EasyOne Pro LAB cost-effective to operate?
The EasyOne Pro LAB is designed to be cost-effective by only requiring an oxygen supply for multiple breath nitrogen washout (MBW). This eliminates the need for expensive SF6 gas, resulting in lower operational costs.
Does the EasyOne Pro LAB offer comprehensive testing?
Yes, the EasyOne Pro LAB is a highly comprehensive system designed for full pulmonary function testing (PFT). In addition to measuring Lung Clearance Index (LCI) and Functional Residual Capacity (FRC) via Multi-Breath Nitrogen Washout (MBW), it integrates several key testing modalities:
- Spirometry: Includes FVC, FVL, SVC, MVV, and Pre/Post comparisons.
- DLCO: Diffusing Capacity of the Lungs for Carbon Monoxide.
- Provocation Testing.
This system utilizes TrueFlow and TrueCheck technology to ensure highly accurate results across all these functions and is capable of determining lung volumes using only an oxygen supply, eliminating the need for expensive SF6 gas or a Body Box.
Which advanced lung function tests are supported?
The EasyOne Pro LAB provides comprehensive pulmonary function testing, complying with both 2019 and 2005 ATS/ERS standards. It supports an extensive list of testing modalities, including:
- Multiple Breath Nitrogen Washout (MBW): This key function measures Functional Residual Capacity (FRC) and the Lung Clearance Index (LCI), crucially using only oxygen, eliminating the need for expensive SF6 gas.
- Diffusion Capacity of the Lung (DLCO).
- Spirometry: Covers essential measurements like FVC (Forced Vital Capacity), FVL, SVC, MVV, and Pre/Post comparisons.
- Provocation Testing.
Additionally, the system provides advanced result interpretation with Z-score, Lower Limit of Normal (LLN), and percent predicted calculations.
Does the EasyOne Pro LAB comply with industry standards?
Yes, the EasyOne Pro LAB complies with both the 2019 and 2005 ATS/ERS (American Thoracic Society/European Respiratory Society) standards, ensuring adherence to established guidelines for lung function testing.
Is EMR connectivity and data export seamless?
Yes, the EasyOne Pro LAB ensures seamless data management and integration through the EasyOne Connect software.
Key features for connectivity and data output include:
- Robust EMR Connectivity: The system offers flexible integration options via industry standards such as HL7, XML, GDT, and API.
- Easy Data Export: Results and information can be readily exported as both PDF files and raw data for archiving or further analysis.
Which languages are supported by the EasyOne Pro LAB user interface?
The EasyOne Pro LAB features a user interface that supports multiple languages, including English, Chinese, Croatian, Danish, Dutch, Finnish, French, German, Italian, Japanese, Norwegian, Portuguese, Russian, Spanish, Swedish, Turkish, and Vietnamese.
What components are included with the EasyOne Pro LAB system?
The EasyOne Pro LAB package includes:
- DLCO valve
- Flow Sensor
- Patient gas supply tube
- One-way valve
- Gas hoses
- Temperature/humidity sensor
- DLCO and Oxygen regulators (E or H/K)
How does the EasyOne Pro LAB ensure patient hygiene?
The EasyOne Pro LAB is engineered with several features to ensure optimal hygiene and prevent cross-contamination during testing:1. Hygienic Consumables: It uses specialized Spirette and Barriette consumables which are designed to eliminate the risk of patient-to-patient cross-contamination.2. Cleanable Design: The device has a compact design with smooth surfaces, making the unit easy and quick to clean.
What are the system's dimensions and weight?
The EasyOne Pro LAB is engineered for efficiency and features a compact design, eliminating the need for a large Body Box for lung volume measurements. This makes it highly suitable for clinical environments where space optimization is necessary. Its specifications are as follows:<ul><li>Dimensions: 10.6 in x 13.2 in x 10.6 in</li><li>Weight: 17.65 lb</li></ul>The device also features smooth surfaces for easy cleaning and maintenance.
