- Condition: Factory New
- Warranty: 2 Years
- Weight: 0.14 lb
- Real time Flow/Volume and Volume/Time curves on your PC for comprehensive spirometry
- Power via USB - No internal memory, no display, no maintenance
- Wide range of selectable parameters
- Embedded temperature sensor for BTPS conversion
-
Learn more:
-
Purchasing Restriction: Medical license or prescription required
- MFR: MIR Ships from Manufacturer
- MPN: 911006
- Phone: (844) 464-7872
Frequently asked questions
Does it feature a bi-directional digital turbine sensor?
Yes, the MIR Minispir Spirometer utilizes a high-quality bi-directional digital turbine flow sensor for precise real-time respiratory measurements.
This advanced sensor setup is complemented by an integrated semiconductor temperature sensor (with a range of 0 to 45 °C), which is crucial for accurate BTPS conversion (Body Temperature, Pressure, Saturated).
The system provides high accuracy for clinical use:
- Volume Accuracy: ± 3% or 50 mL
- Flow Accuracy: ± 5% or 200 mL/s
- Dynamic Resistance at 12 L/s: < 0.5 cmH₂O/L/s
This precision is key to performing comprehensive testing, including crucial PRE/POST bronchodilator comparisons.
Is the spirometer powered only by USB?
Yes, the MIR Minispir Spirometer is powered directly by the USB connection to your PC. This design eliminates the need for a separate power source, display, or internal memory, contributing to its low-maintenance nature.
Is comprehensive WinspiroPRO software included?
Yes, the MIR Minispir Spirometer includes the powerful WinspiroPRO CD software.
Since this is a PC-based device powered via USB, the software is central to its operation, providing real-time data visualization and analysis. It is compatible with Windows XP through 10.
Key features of the WinspiroPRO software include:
- Extensive Testing: Supports comprehensive protocols including FVC, VC, MVV, and Pre/Post Bronchodilator comparisons.
- Advanced Diagnostics: Provides Lung Age Estimation (ELA) and supports specialized Methacoline/mannitol provocation tests.
- Pediatric Incentives: Includes engaging pediatric incentive animations to improve patient cooperation.
- Data Export: Allows easy export of results into standard formats like Word, Excel, and PDF.
- Real-Time Display: Visualizes Flow/Volume loops and Volume/Time curves directly on your connected PC screen.
Does the spirometer measure comprehensive parameters?
Yes, the MIR Minispir Spirometer is designed for complete respiratory analysis and measures an extensive list of over 20 spirometry parameters, enabling detailed clinical assessment and interpretation.
Key Test Types Supported:
- FVC (Forced Vital Capacity)
- VC/IVC (Slow/Inspiratory Vital Capacity)
- MVV (Maximum Voluntary Ventilation)
- PRE/POST Bronchodilator Comparison
Advanced Diagnostic Capabilities:
The device, coupled with the WinspiroPRO software, offers unique features for advanced testing:
- Provocation Tests: Supports Methacoline and mannitol challenge testing.
- Lung Age Estimation (ELA): Provides a valuable metric for patient counseling.
- Real-Time Data: Displays real-time flow/volume loops and volume/time curves directly on the connected PC.
- Pediatric Use: Includes dedicated pediatric incentive animations to help ensure patient compliance.
What is the volume accuracy of the MIR Minispir Spirometer?
The volume accuracy of the MIR Minispir Spirometer is ± 3% or 50 mL.
Can the MIR Minispir Spirometer be used for pre and post bronchodilator comparison?
Yes, the MIR Minispir Spirometer can be used for pre/post bronchodilator comparison with a wide range of selectable parameters.
What components are included with the Minispir Spirometer?
The MIR Minispir Spirometer is provided as a complete kit for immediate PC-based respiratory analysis. Since the device is USB line-powered, no separate power adapter is required.
Your purchase includes the following essential components:
- MIR Minispir Spirometer Unit: The core diagnostic device.
- WinspiroPRO CD: The comprehensive software necessary for all testing capabilities (FVC, MVV, etc.), real-time data visualization, and professional report generation.
- USB Cable: Connects the spirometer to your PC, supplying both power and data transmission.
- Nose Clip: An accessory vital for performing accurate spirometry measurements.
- Carrying Case: For easy and safe storage and transportation of the compact unit.
- Users Manual CD: Documentation to guide setup and operation.
Does the Minispir support challenge testing?
Yes, the MIR Minispir Spirometer is specifically designed to support advanced provocation testing.This includes:
- Support for Methacoline/mannitol provocation tests.
- Comprehensive PRE/POST bronchodilator comparisons.
All testing protocols and interpretations are managed via the included, powerful WinspiroPRO software on your connected PC.
Is the Minispir spirometer easy to set up?
Yes, the MIR Minispir Spirometer is designed for extremely simple setup and portability, emphasizing a plug-and-play PC-based experience. Its design minimizes complexity and maintenance requirements.
Key features contributing to its ease of use:
- Simple Connectivity: The device connects directly to your PC via a USB cable (included). It is entirely line-powered by the USB port, eliminating the need for internal memory or a dedicated display.
- Zero Maintenance: Since it operates entirely via the PC connection, it requires no ongoing internal maintenance.
- Compact and Portable: Weighing only 0.14 lb (65 grams), the unit is ultra-light and comes with a carrying case for easy transport between clinical settings.
- Included Software: Setup and operation are driven by the included WinspiroPRO CD, which is compatible with Windows XP, Vista, 7, 8, and 10.
Is the included WinspiroPRO software Windows compatible?
Yes, the MIR Minispir Spirometer is PC-based and relies entirely on the included WinspiroPRO software for advanced data processing and analysis. The software offers excellent compatibility across a wide range of operating systems, specifically supporting:
- Windows XP
- Windows Vista
- Windows 7
- Windows 8
- Windows 10
This broad compatibility ensures seamless integration into most clinical environments.
