Key Features
  • SKU: MDY-121-002174-00
  • Condition: Factory New
  • Country of Origin: China
  • Warranty: 3 Years
  • 10.1″ multi-gesture, capacitive touchscreen display with an intuitive user interface
  • TrueBP quickly measures blood pressure on inflation in about 15 seconds
  • Orthostatic BP helps to assess a patient’s fall risk
  • Stores up to 5,000 measurements, accessible by patient ID for easy review

  • Learn more:

Contact The Manufacturer
  • MFR: Mindray
    Ships from Manufacturer
  • MPN: 121-002174-00
  • Phone: (888) 850-4597
$1,065.99
Est. Delivery:

Earn [points_amount] when you buy this item.

Shop with Confidence

Free Shipping

Free Returns

Payment Options

Price Match Guarantee

Sales Tax Exemption

Dedicated Account Managers

Description

The Mindray VS 9 Vital Signs Monitor is available in several configurations to meet your needs including NIBP, pulse rate, SpO2, and temperature options.

Warranty: 3 Years.

Note: Pictured barcode scanner is sold separately. The exergen thermometer and other optional accessories are ONLY included WHEN selected as an option on the configurations drop down menu.

Note II: The Mindray VS9 Vital Signs Monitor Lithium Ion Battery (#115-034132-00) is sold separately.

Boasting a variety of functionality and parameters that provide tools to support clinical decisions, the VS 9 Vital Signs Monitor is ideally suited for spot check and continuous vital signs monitoring which helps clinicians get a complete picture of patient health. By elevating a department's workflow to new heights, it also addresses the needs of low acuity areas. Thanks to capacitive touchscreen technology, like you see with your smartphone, the VS 9 is extremely easy and efficient to use. It can be connected so clinicians can send vital signs at the point of care (POC) reducing the possibility of errors. With Mindray’s innovative BeneVision Distributed Monitoring System (DMS) caregivers can centrally view patient information sent from the POC.

Features

Mindray VS 9 Vital Signs Monitor Features

  • 10.1″ multi-gesture, capacitive touchscreen display with an intuitive user interface.
  • Configurable workflows defined by department.
  • TrueBP quickly measures blood pressure on inflation in about 15 seconds.
  • Manual, automatic, and customizable NIBP measurement modes offer flexibility for various clinical applications.
  • Orthostatic BP helps to assess a patient’s fall risk.
  • BP Average functionality provides an average BP over a specified time and a number of measurements.
  • Available SpO2 technology includes Masimo SET (standard) or Nellcor Oximax.
  • Temperature options include: Exergen Temporal Scanner, and Welch Allyn stand-alone SureTemp Plus.
  • Low flow sidestream CO2 provides measurements of FiCO2, etCO2, and awRR with a CO2 waveform.
  • Standard Modified Early Warning Score (MEWS) offers support for clinical decisions.
  • Customize up to 30 manual inputs, such as respiration rate, glucose, and height.
  • Infographic pain scale to document pain level.
  • Stores up to 5,000 measurements, accessible by patient ID for easy review.

Specifications

Mindray VS 9 Vital Signs Monitor Specifications

Physical Specifications:

  • Dimensions: 10.8" H x 7.3" W x 5.3" D (27.5 cm H x 18.5 cm W x 13.5 cm D).
  • Screen: 10.1-inch, 1280 x 800 pixels standard capacitive touchscreen supports multi-touch operation.
  • Weight: 7.5 lb (3.4 kg).

Bluetooth:

  • Protocol: Bluetooth 5.
  • Modulation Mode: GFSK.
  • Operating Frequency: 2402 MHz to 2480 MHz.
  • Wireless Data Rate: 2 Mbps, 1 Mbps, 125 kbps.
  • Output Power: ≤ 8 dBm ± 4 dB
  • Data Security: AES128.

Interfacing:

  • Main Unit: AC power connector (1), Network connector (1), RJ45 USB 2.0 connector (2), Multi-Functions connect (1), Equipotential grounding terminal (1), External battery connector (1).
  • Barcode Scanner: Support 1D and 2D barcode.
  • Thermal Recorder: 3 traces (paper 50 mm width, 20 m length).
  • Data Output: HL7, eGateway, VitalsLink (Cerner).
  • Auth. Management: MLDAP, Imprivata.

Power:

  • Line Voltage: 100 to 240 VAC (±10 %).
  • Current: 0.9 to 0.5A.
  • Frequency: 50/60 Hz (±3 Hz).
  • Battery: 5600mAh rechargeable smart Li-ion battery.
  • Recharge Time (Power Off): 4 hours to 100%.

Environmental Requirements:

  • Temperature:
    • Operating: 0 to 40 °C (without CO2). 5 to 40 °C (with CO2).
    • Storage: -20 to 60 °C.
  • Humidity:
    • Operating: 15 to 95 % (non condensing).
    • Storage: 10 to 95 % (non condensing).
  • Barometric:
    • Operating: 120 to 805.5 mmHg (57 to 107.4 kPa) (without CO2). 430 to 790 mmHg (57.3 to 105.3 kPa) (with CO2).
    • Storage: 120 to 805.5 mmHg (16 to 107.4 kPa) (without CO2). 430 to 790 mmHg (57.3 to 105.3 kPa) (with CO2).

Configurations

Mindray VS 9 Vital Signs Monitor Configurations

  • #121-002174-00: Standard (NIBP and Pulse Rate Only).
  • #121-002177-00: with Nellcor OxiMax SpO2, NIBP, and Pulse Rate.
  • #121-002176-00: with Masimo SpO2, NIBP, and Pulse Rate.
  • #121-002421-00: with NIBP, Pulse Rate, Nellcor OxiMax SpO2, and TrueTemp.
  • #121-002182-00: with Nellcor OxiMax SpO2, NIBP, Pulse Rate, and Exergen Temporal Temp.
  • #121-002424-00: with NIBP and Pulse Rate, Masimo SpO2, and TrueTemp.
  • #121-002181-00: with Masimo SpO2, NIBP, Pulse Rate, and Exergen Temporal Temp.
  • #121-002186-00: with Nellcor OxiMax SpO2, NIBP, Pulse Rate, and Low-Flow Sidestream CO2.
  • #121-002185-00: with Masimo SpO2, NIBP, Pulse Rate, and Low-Flow Sidestream CO2.
  • #121-002428-00: with NIBP and Pulse Rate, Nellcor OxiMax SpO2, TrueTemp, and Mindray Integrated CO2.
  • #121-002191-00: with Nellcor OxiMax SpO2, NIBP, Pulse Rate, Exergen Temporal Temp, and Low-Flow Sidestream CO2.
  • #121-002425-00: with NIBP and Pulse Rate, Masimo SpO2, TrueTemp, and Mindray Integrated CO2.
  • #121-002190-00: with Masimo SpO2, NIBP, Pulse Rate, Exergen Temporal Temp, and Low-Flow Sidestream CO2.
