Midmark 626 Barrier-Free Examination Chair

The Midmark 626 chair base includes a comprehensive set of controls and components designed for safety, workflow efficiency, and maximum patient accessibility.

Standard Operational Controls

• Hand and Foot Controls: Included for powered adjustments of the chair sections. (Note: You can choose between wired or wireless configurations when ordering.)
• Quick Exam Feature: A one-touch control for rapid elevation to the default examination position.

Core Utility and Positioning Features

• Barrier-Free Accessibility: The chair achieves an extremely low height of 15.5 inches (uncompressed) to simplify patient transfer and minimize staff assistance.
• Pelvic Tilt Mechanism: Allows for a 5.2° adjustment angle to optimize lower-body positioning.
• Drawer Heater: Integrated beneath the seat for warming supplies, maintaining a temperature range of 92 °F to 112 °F.
• Stirrups and Standard Accessory Receivers (for tool-free integration).
• Hospital-Grade Electrical Receptacles: Tamper-resistant outlets included on both the left and right sides.

Safety and Connectivity

• Active Sensing Technology: A critical safety feature that automatically pauses table movement upon detection of disruptive impact.
• Midmark IQconnect Framework: Enables seamless EMR data transfer and device integration.
• Clean Assist Roller System: Included to simplify moving the heavy chair base (435 lb) for thorough cleaning.
• The chair supports a patient weight capacity of 650 lb (295 kg).

The Midmark 626 Barrier-Free Examination Chair is engineered for exceptional strength and safety, allowing it to accommodate a wide range of patients.It supports a substantial patient weight capacity of 650 lb (295 kg).

The Midmark 626 is designed with critical dimensions to ensure barrier-free patient access and precise positioning:

• Low Barrier-Free Height: The chair achieves a compressed height as low as 14.6 inches (36 cm), allowing most patients to place their feet flat on the floor for safe transfers.
• Adjustable Operating Height: The uncompressed height range is from 15.5 inches (39 cm) (low) to a maximum of 37 inches (94 cm) (high).
• Overall Length: When the footrest is fully extended, the chair measures 76 inches (193 cm) in length.

Yes, the Midmark 626 Barrier-Free Examination Chair includes an integrated Drawer Heater as a standard component.

This feature is designed for convenience, allowing you to warm supplies used during procedures, enhancing patient comfort and clinical efficiency.

Key specifications for the drawer heater:

• Power Consumption: 24.6 Watt
• Temperature Range: Maintains a temperature between 92 °F and 112 °F (when operating at 115 VAC input and 70 °F ambient temperature).

Yes, the Midmark 626 is specifically engineered for integrated operation using the Midmark IQconnect framework.

This advanced technology is crucial for optimizing clinical workflow and allows for:

• Seamless Data Transfer: Direct transfer of patient data to your Electronic Medical Records (EMR) system.
• Integrated Operation: Centralized control and operation of the chair (and other IQ-series devices) from a unified interface, often displayed on a computer screen.

This high level of connectivity contributes directly to enhanced operational efficiency within the clinical environment.

The Midmark 626 Barrier-Free Examination Chair includes several advanced features focused on patient and clinician safety:

• Active Sensing Technology: This crucial feature automatically pauses chair movement immediately upon detecting an unexpected or disruptive impact, ensuring safety during positional changes.
• Barrier-Free Accessibility: The chair achieves an exceptionally low compressed height (as low as 14.6 inches), allowing the majority of patients to place their feet flat on the floor for simplified and safer transfers.
• High Patient Capacity: The chair is structurally designed to safely support a patient weight capacity of up to 650 lb (295 kg).
• Electrical Safety: It incorporates hospital-grade, tamper-resistant electrical receptacles on both sides for secure access when powering other medical devices.
• Compliance: The chair adheres to strict international safety requirements, including standards such as ANSI/AAMI ES60601-1 and CAN/CSA-C22.2 No. 60601-1.

Yes, the Midmark 626 chair base is engineered to support the Premium Comfort System.

Important Note: This comfort system is integrated into the required upholstered top and armrests, which are sold separately from this base unit. You must purchase a compatible top to utilize this feature.

When utilized, the Premium Comfort System enhances patient comfort by:

• Employing an advanced elastomeric material over a seat cutout.
• Providing a highly supportive, chair-like feel during examinations.

Compatible upholstery tops are available in two sizes: 28 inches (W) x 60 inches (L) or 32 inches (W) x 60 inches (L).

The Midmark 626 Barrier-Free Examination Chair operates on 115 VAC, 50/60 Hz, 12 A. It also features hospital-grade electrical receptacles on both the left and right sides, with an electrical draw of 4 A, ensuring convenient and safe power access for other devices during examinations.

The Midmark 626 examination chair base can be configured to meet specific practice needs, primarily through these key options:

• Movement Controls: You can select between the standard Wired Hand and Foot Controls or upgrade to the Wireless Hand and Foot Controls.
• Integrated Patient Scale: The chair can be configured with IQscale integration, providing an accurate, integrated weighing system that uses the IQconnect framework for seamless EMR data transfer.
• Heated Comfort: Configurations are available with Heated Upholstery for enhanced patient comfort.

Note: While the chair base includes stirrups, the drawer heater, and the pelvic tilt mechanism, upholstered tops (available in 28-inch or 32-inch widths) and armrests must be purchased separately.

Yes, the Midmark 626 is engineered with multiple features to ensure precise and easy patient positioning, which optimizes clinical accuracy and comfort. These include:

• Pelvic Tilt: Features a 5.2° pelvic tilt mechanism, which is essential for accurate positioning during lower body examinations.
• Powered Back Section: The back section movement is powered, providing continuous support and allowing for smooth adjustments using the standard Hand and Foot Controls.
• Clinical Benefits: The enhanced positioning capabilities help facilitate more accurate blood pressure measurements.
• Quick Exam: The chair features a Quick Exam function for rapid, one-touch elevation to the necessary examination position.
