Maxtec MAX-12A Oxygen Cell

This Maxtec MAX-12A O₂ Cell is an FiO2 (Fraction of Inspired Oxygen) Sensor that is compatible with a variety of systems. Primarily used with Ventilator Machines and Patient Monitors. See below for specific compatibility information.

Note: Can only be shipped within the U.S.

Maxtec MAX-12A O₂ Cell Specifications

• Compatible with:
  • Air Shields Isolette.
  • Analytical Instruments.
  • City Technologies.
  • Criticare: 8100 Poet, 8500 Poet.
  • Envitec.
  • Datex-Ohmeda Centiva S/5.
  • Hill Rom: C2000, Isolette Incubator.
  • Hamilton: Galileo, Raphael, Arabella, Multinex, Analys.
  • Hudson RCI.
  • Isolette C2000 and 8000.
  • Maxtec.
  • Nuova.
  • Philips Respironics NeoPAP.
  • Taema Cesar (new).
  • Teledyne.
  • Viamed.
• Equivalent to:
  • Analytical Industries: PSR-11-917-M1.
  • Biotest: A 103.
  • City Technologies: MOX-1.
  • Criticare: 644.
  • Datex Engstrom: 0600-00-0002.
  • Drager: MU24903.
  • Envitec: OOM-102, OOM-106.
  • GE Marquette: R-22.
  • Hamilton Cells: HM-12.
  • Henleys: 5556.
  • Hill-Rom: R-22.
  • Hudson RCI: 5566, V-12.
  • Infrasonics: R-22.
  • Maxtec: MAX-12A R109P48.
  • Mercury Medical: 10-103-15.
  • Narco Med: R-22.
  • Nuova: E-17/A2.
  • Pacifitech: PT-12AIR.
  • SensorTech: ST-12.
  • Spacelabs: 90514.
  • Teledyne: R-22MED.
  • Viamed: R-22Med.
• G0-120 (Maxtec Equivalent) Specifications:
  • Response Time: Less than 12 seconds.
  • Connector Type: 3-Pin Molex.
• R109P48 (Maxtec) Specifications:
  • Output: 17. +/- 14.0 mV.
  • Response Time: Less than 12 seconds.
  • Linearity: +/- 3.0% of full scale.

Maxtec MAX-12A O₂ Cell Configurations

• #G0-120: MAX-12A Cell Equivalent manufactured by Cables and Sensors.
  • Warranty: 16 Month Shelf Life.
• #R109P48: Maxtec MAX12A Cell manufactured by Maxtec.
  • Warranty: 14 Month Shelf Life.

Maxtec MAX-12A O₂ Cell Literature

Maxtec KOH Oxygen Sensors Safety Data Sheet

Maxtec MAX-12A Oxygen Cell Specifications Sheet
