- Condition: Factory New
- Warranty: 1 Year
- Weight: 2.0 lb
- Made for use with the DUS60 Ultrasound (#DUS60_mainunit)
- Applications: OB, Gynecology, and Urology
- Scanning Angle: 40 mm
- Cable Length: 2000 mm
-
Learn more:
- MFR: Edan Ships from Manufacturer
- MPN: E741
- Phone: (888) 850-4597
Frequently asked questions
Is this transducer compatible with other ultrasound systems besides the Edan DUS 60?
The Edan Endorectal Transducer E741-2 is specifically designed to be compatible with the Edan DUS 60 Digital Ultrasonic Diagnostic Imaging System. This ensures seamless integration and optimal performance.
Is the needle guide bracket included?
No, the Transrectal Transducer Needle Guide Bracket is available for purchase separately. It is not included with the main unit.
Is this a new or refurbished transducer?
The Edan Endorectal Transducer E741-2 is a factory new product, ensuring optimal performance and longevity.
What are the available frequency settings for this transducer?
The transducer has adjustable fundamental frequencies of 6.5 MHz, 7.5 MHz, and 8.5 MHz, harmonic frequencies of 9.0 MHz and 9.4 MHz, and Doppler frequencies of 5.5 MHz and 6.5 MHz.
What is the scanning length of this transducer?
The scanning length/footprint of the Edan Endorectal Transducer E741-2 is 40 mm.
What is the depth range that this transducer can image?
The imaging depth is adjustable from 19 to 117 mm, allowing for detailed visualization at varying depths during urological procedures.
How many elements does this transducer have?
This transducer features an endocavity linear array with 80 elements, providing detailed imaging. Its 40 mm scanning length helps ensure comprehensive coverage for urological diagnostic imaging.
How detailed is the imaging capability?
This transducer is engineered to provide detailed diagnostic imaging, specifically optimized for Urology applications, through its specialized components and robust frequency range.Heres a breakdown of its core imaging specifications:<ul><li>Array Format: Endocavity linear array.</li><li>Element Count: Features 80 active elements, which contributes to high-resolution image acquisition.</li><li>Bandwidth: Operates across a wide bandwidth of 5.0 to 10.0 MHz, utilizing fundamental frequencies up to 8.5 MHz.</li><li>Depth and Length: The scanning length (footprint) is 40 mm, and the imaging depth is adjustable, ranging from 19 mm to 117 mm.</li></ul>
Is this transducer suitable for urological applications?
Yes, the Edan Endorectal Transducer E741-2 is optimized for urological procedures, offering detailed endocavity linear array imaging suitable for various urological applications.
What is the PW Velocity of this transducer?
The PW (Pulsed Wave) Velocity of the Edan Endorectal Transducer E741-2 is Max 0.69 m/s (± 60°).
