Eagle Group MHC 4-Compartment Sinks, 314 Series Coved Corner

Yes, this heavy-duty commercial sink is equipped with a substantial backsplash designed for optimal wall integration and hygiene:

• Height: The unit features a 9 1/2-inch standard backsplash.
• Design: It includes a 1-inch upturn and a tile edge which allows for easy, flush installation against wall surfaces, improving sanitation and protecting the wall from water damage.

Yes, this sink includes a waste drain for each compartment to ensure optimal readiness for installation.

Key specifications for the included drains are:

• Type: Basket-type waste drain
• Opening Fit: Designed for a 3 1/2-inch opening
• Outlet Size: Features a 1 1/2-inch outlet

Yes, the four sink bowls in the Eagle Group MHC 314 Series are specifically designed for maximum capacity and efficient sanitation. This is achieved through several features:

• Deep-Drawn Construction: The bowls feature a deep-drawn, one-piece seamless construction for superior durability and capacity.
• Maximized Volume: The rectangular shape and generous radius (minimum 3 inches) maximize the usable wash space.
• Substantial Depth: The standard water level is 13 1/2 inches, providing excellent washing depth for commercial use.
• Premium Material: The bowls are constructed from heavy-gauge Type 304 stainless steel, ensuring long-term resistance to corrosion and rigorous use.

Yes, the sink’s support system is built for stability and demanding environments:

• Legs: Constructed from 1 5/8” diameter heavy-gauge galvanized tubing.
• Stability: Leg gusset assemblies (plated 12-gauge) are welded adjacent to the sink bowls for maximum support. This is reinforced by 1” diameter heavy-gauge galvanized crossbracing.
• Adjustability: The unit features high-impact, corrosion-resistant, fully adjustable bullet feet to ensure it remains level on uneven surfaces.

The drainboards on the Eagle Group MHC 4-Compartment Sinks are specifically designed for efficient water removal and hygiene, preventing water from pooling.

Key optimization features include:

• They feature V-creased construction which guarantees positive drainage.
• The drainage system utilizes a standard “Swirl-away” design for effective waste removal.
• The drainboards, like the rest of the sink top, are constructed from heavy-gauge Type 304 stainless steel for superior durability and corrosion resistance.
• Available drainboard lengths are 18” or 24”, depending on the configuration selected.

Yes, the entire wet area of the unit—including the sink bowls, top, drainboards, and backsplash—is constructed from heavy gauge Type 304 stainless steel.

This robust material is specifically chosen for demanding commercial environments, providing superior benefits:

• Exceptional Durability: The heavy gauge steel ensures long-term resistance to rigorous, high-volume use.
• Corrosion Resistance: Type 304 stainless steel offers excellent protection against rust and staining.

Furthermore, the four sink bowls feature a deep-drawn, one-piece seamless construction with sanitary coved corners (minimum 3” radius) to maximize capacity and simplify cleaning.

The sink is built for commercial use and provides several standard connection points for easy installation:

• Water Supply Connection: The unit requires 1/2” IPS connections for both hot and cold supply lines.
• Faucet Holes: Faucet holes are pre-punched at 1 1/8” diameter on standard 8” centers, ready for faucet installation.
• Waste Drain: A basket-type waste drain is included. It is designed to fit the 3 1/2” bowl opening and features a **1 1/2” outlet.

The four-compartment sinks feature bowls constructed from heavy gauge Type 304 stainless steel using a deep-drawn, one-piece seamless process, ensuring maximum durability and sanitation. The rectangular bowls also feature coved corners (minimum 3-inch radius) to simplify cleaning.

The sink bowls are available in the following dimensions:

• 20 inches x 16 inches
• 24 inches x 24 inches

All compartments maintain a standard working water level of 13 1/2 inches.

The coved corner design is a key feature of the 314 Series, specifically engineered for high-volume environments requiring maximum sanitation and compliance.

This design provides several critical benefits:

• Superior Hygiene: The coved corners feature a generous radius (minimum 3”) that eliminates the sharp angles and tight crevices where food particles, dirt, and bacteria often accumulate.
• Simplified Cleaning: This seamless construction makes the entire bowl significantly easier and faster to wipe down and sanitize thoroughly.
• Maximum Durability: The coved corner is integral to the deep-drawn, one-piece seamless construction of the heavy-gauge Type 304 stainless steel, enhancing structural integrity and longevity.

Yes, the sink bowls are constructed with a generous radius and seamless design to optimize capacity and hygiene.

• The coved corners feature a minimum 3-inch radius, which aids in cleaning.
• This radius is integral to the deep-drawn, one-piece seamless construction, maximizing usable volume while ensuring a highly sanitary environment.
