Eagle Group MHC 310 Series Sinks

Yes, this sink is constructed from heavy-duty, commercial-grade materials designed for maximum durability and hygiene.

• Primary Surfaces: The sink bowls, top, drainboards, and backsplash are all made from heavy gauge type 304 stainless steel. This material is selected for its superior corrosion resistance and longevity.
• Hygienic Finish: The entire assembly is fuse-welded and planished, resulting in a continuous, germ-free seamless interior and a consistent satin finish across all welded areas.
• Structural Support: Stability is maximized by using 1 5/8” diameter heavy-gauge galvanized tubing legs. These legs are reinforced with plated 12-gauge gussets and crossbracing, ensuring robust support and enhanced stability.

Yes, the Eagle Group MHC 310 Series sink is equipped with high-impact, corrosion-resistant, fully adjustable bullet feet.

This feature allows for:

• Accurate leveling on uneven surfaces.
• Superior stability required in demanding commercial or industrial settings.

The adjustable feet are integrated into the heavy-duty support structure, which features 1 5/8” diameter heavy-gauge galvanized tubing legs for maximum rigidity.

The MHC 310 Series Sinks include three deep, commercial-grade sink bowls designed for high-volume use. Each individual bowl measures:

• Width x Length: 14 inches x 10 inches
• Depth: 9 1/2 inches

These bowls are constructed from heavy gauge Type 304 stainless steel and are fuse-welded to create a one-piece, seamless interior, ensuring maximum hygiene and durability.

The top surface of the sink is pre-punched for standard commercial faucet installation, featuring the following specifications:

• Diameter: 1 1/8 inches
• Spacing: Punched on 8-inch centers

The sink features a standard, full-length backsplash that is 9 1/2 inches high.

Constructed from heavy gauge Type 304 stainless steel—the same material used for the bowls and drainboards—it is fuse-welded into a single, seamless, and hygienic unit.

This robust backsplash is designed for easy installation and maintenance, featuring:

• A 1-inch upturn at the top edge.
• A specialized tile edge for seamless integration with wall surfaces.

The Eagle Group MHC 310 Series is engineered for robust performance in highly demanding commercial, industrial, and institutional environments where hygiene and heavy use are primary concerns. The sink’s durability is based on its heavy-gauge Type 304 stainless steel construction and enhanced stability features.

These sinks are ideal for:

• Commercial Kitchens: Built to handle high-volume use and demanding cleaning cycles.
• Medical and Laboratory Facilities: The fuse-welded, one-piece seamless interior ensures a germ-free environment essential for superior sanitation.
• Industrial Settings: Provides maximum stability and longevity, supported by 1 5/8” diameter galvanized tubing legs and heavy-gauge crossbracing.

Yes, the Eagle Group MHC 310 Series is engineered specifically for superior hygiene in demanding environments, resulting in a germ-free seamless interior.

Key features that ensure sanitation and durability include:

• Seamless One-Piece Construction: The entire unit, including the sink bowls, top, and drainboards, is fuse-welded and planished into a continuous, seamless assembly. This process eliminates crevices, ensuring a germ-free interior.
• Premium Materials: The working surfaces are constructed from heavy-gauge Type 304 stainless steel, providing excellent corrosion resistance and simplified cleaning.
• Safety and Maintenance: All exterior corners are bullnosed for safe handling and to further simplify wiping and sanitation.
• Uniform Finish: Welded areas are meticulously blended using a high-speed belt to maintain a continuous, uniform satin finish across the entire surface.

The MHC 310 Series sinks are available in three distinct configurations, all featuring the same three 14” x 10” sink bowls that are 9 1/2” deep. The overall width of the unit remains consistent at 21 11/16” across all options.

The variations are defined by the overall length and the size of the integrated drainboards:

• 60” Overall Length: Includes two 12” drainboards.
• 72” Overall Length: Includes two 18” drainboards.
• 84” Overall Length: Includes two 24” drainboards.

The MHC 310 Series Sinks come equipped with basket type waste drains. These are designed for effective debris collection and feature a standard 1 1/2-inch outlet.

Yes, the Eagle Group MHC 310 Series Sinks are engineered for superior stability and maximum weight support required in demanding commercial environments. Stability is one of the top selling points.

The sink’s robust base structure includes:

• Heavy-Gauge Legs: Supported by 1 5/8” diameter heavy-gauge galvanized tubing legs.
• Reinforced Gussets: Plated 12-gauge gussets are welded onto a die-cut heavy gauge reinforcing plate to ensure exceptional structural support.
• Front-to-Back Crossbracing: Stability is further enhanced by 1” diameter heavy-gauge galvanized tubing crossbracing that runs front-to-back.
