Eagle Group MHC 3-Compartment Sinks, Spec-Master Fn Series Coved Corner

Yes, this Spec-Master FN Series sink is constructed using heavy-duty, 14 gauge 300 series stainless steel for superior commercial durability and longevity. This material is used for all major components, including the drainboards, backsplash, rolled rims, and the primary structural elements.The heavy-duty construction is reinforced by several key features:

• Robust Leg Structure: Features substantial 1 5/8” diameter stainless steel tubing legs and fully adjustable stainless steel bullet feet.
• Enhanced Stability: Legs are strategically located directly under the sink compartments and secured with stainless steel gussets and heavy-gauge reinforcing corner plates.
• Full Crossbracing: Adjustable 1 1/4” diameter stainless steel crossbracing ensures stability across the entire unit.

Additionally, the sink compartments use state-of-the-art seamless welding techniques and feature sanitary 5/8” radius coved corners for easier cleaning.

Yes, the backsplash is built for durability and hygiene, constructed from heavy-duty 14 gauge 300 series stainless steel.

Its design details ensure maximum utility and wall protection:

• Height: 9 1/2 inches high.
• Integration: Features a 1-inch upturn and a tile edge, allowing seamless integration with surrounding wall finishes.
• Faucets: It is pre-punched with 1 1/8-inch diameter faucet holes on 8-inch centers.

Yes, the Spec-Master FN Series is engineered specifically to maximize hygiene and minimize buildup, which is critical for commercial applications. Key design features include:

• Coved Corners: The sink compartments utilize a full 5/8” radius coved interior. This smooth design eliminates sharp corners, preventing the accumulation of debris and making cleaning significantly easier.
• Seamless Welding: The compartments are constructed using state-of-the-art seamless welding techniques, resulting in a smooth, non-porous interior surface that promotes superior sanitation.
• Safe Edges: All outside corners are bullnosed for enhanced safety and easier cleaning around the perimeter.
• Backsplash: A 9 1/2” high backsplash with a 1” upturn and tile edge helps protect the surrounding wall surfaces from splashing and moisture.

Yes, this Spec-Master FN Series sink is engineered with a heavy-duty support system to ensure maximum stability and durability in rigorous commercial applications. The legs are strategically positioned directly beneath the sink compartments for optimal weight support.

Key features of the support system include:

• Robust Legs: The unit is supported by heavy-duty 1 5/8” diameter stainless steel tubing legs with welded stainless steel gussets.
• Comprehensive Stability: Structural rigidity is enhanced by 1 1/4” diameter adjustable stainless steel crossbracing that runs left-to-right and front-to-back.
• Leveling: The legs feature fully adjustable stainless steel bullet feet for precise leveling on uneven flooring.

Yes, the sink assembly comes standard with a basket-type waste drain for each compartment.

The key specifications for the drain system are:

• The drain fitting is designed to fit the sink bowl’s 3 1/2” opening.
• The waste outlet size is 1 1/2”.

Yes, the Eagle Group Spec-Master FN Series three-compartment sink is engineered with versatility in mind, offering 14 distinct configurations built from highly durable 14 gauge 300 series stainless steel.

Key configuration options include:

• Sink Bowl Sizes: Compartments are available in various sizes, ranging from 20” x 16” up to 28” x 20”.
• Drainboard Customization: Integrally welded drainboards are offered in either 18-inch or 24-inch lengths and can be positioned on the left or right side of the unit.
• Faucet Preparation: While standard models include one set of faucet holes (1 1/8” diameter punched on 8” centers), certain larger sink bowl configurations are equipped to accommodate dual sets of faucet holes.

The Spec-Master FN Series sink is engineered to accommodate standard commercial faucets.

Key plumbing specifications for installation are:

• Faucet Hole Size: 1 1/8 inches in diameter.
• Faucet Spacing: Holes are punched on standard 8-inch centers.
• Water Supply Connection: Requires a 1/2-inch NPS connection for both hot and cold lines.

Note that the unit features a 9 1/2-inch high backsplash. While standard units have one set of faucet holes, certain larger configurations include two sets of holes.

The Spec-Master FN Series sink is designed with specific water containment levels to manage heavy commercial use and prevent overflow:

• The standard Water Level (operating level) is 14 inches.
• The Flood Level (maximum overflow safety margin) is 17 inches.

This generous 17-inch flood level provides a significant safety margin against potential overflows in demanding environments. Additionally, the unit features a 9 1/2-inch high backsplash for enhanced wall protection.
