Eagle Group MHC 2-Compartment, Utility Sinks With Square Corner Construction

Yes, this utility sink is designed for heavy-duty commercial environments, utilizing high-quality, durable materials and robust structural reinforcement. The construction ensures longevity and superior resistance in demanding settings.

• Premium Material Gauge: The main body of the sink is constructed from robust 16 gauge stainless steel, which offers exceptional rigidity and resistance to impact compared to thinner gauges.
• Corrosion Resistance: Configurations are available using either highly corrosion-resistant Type 304 or durable Type 430 stainless steel grades.
• Superior Stability: Stability is maximized by the use of 1 5/8” diameter heavy-gauge galvanized legs, which are positioned directly under the sink bowls and secured with 12-gauge leg gussets welded to a heavy-gauge reinforcing plate for maximum load support.

Yes, the Eagle Group MHC utility sink is engineered for maximum stability and exceptional weight support, making it suitable for heavy-duty commercial or industrial environments.

Key features ensuring its high stability include:

• Optimized Leg Placement: The support legs are positioned directly beneath the sink bowls to maximize load-bearing capacity and stability.
• Robust Reinforcement: Stability is guaranteed by 12-gauge leg gussets that are welded to a heavy-gauge reinforcing plate underneath the sink bowls.
• Durable Support Structure: The main support structure uses 1 5/8” diameter heavy-gauge galvanized tubing.
• Adjustable Leveling: It is supported by high-impact, corrosion-resistant 1-inch adjustable bullet feet for precise leveling on uneven surfaces.

The Eagle Group MHC utility sink line offers extensive configurations to meet various heavy-duty requirements. All models feature durable 16-gauge stainless steel construction and deep 13 3/8-inch compartments.

Key customization options include:

• Material Grade: Choose between Type 304 or Type 430 stainless steel.
• Size and Bowl Dimensions: A wide variety of overall dimensions are available, with bowl sizes ranging from 18” x 18” up to 24” x 30”.
• Drainboard Configuration: Sinks can be ordered with no drainboard, a single drainboard, or dual drainboards. These are available in 18-inch or 24-inch lengths and may be detachable or welded, depending on the specific model selected.

Yes, this utility sink is highly versatile and offered in multiple configurations that include drainboards, allowing you to optimize your workspace.

Available drainboard options include:

• Availability: Configurations are offered both with and without drainboards.
• Size Options: Drainboards are available in 18-inch or 24-inch lengths.
• Placement: You can select models featuring a single drainboard or configurations with two drainboards (one on each side).
• Construction: Depending on the specific configuration chosen, the drainboards may be either welded or detachable.

Yes, the two-compartment utility sink is designed with substantial depth to handle large wash loads typical of commercial and industrial settings.

Each bowl measures 13 3/8 inches deep, providing high capacity for a wide variety of utility tasks.

Yes, this utility sink is designed with standard commercial plumbing dimensions to ensure compatibility and ease of installation. It features connections for standard fittings:

• Faucet Ready: The sink features 1 1/8” diameter faucet holes punched on standard 8-inch centers.
• Water Supply: Connections for both hot and cold water lines utilize standard 1/2” IPS (Iron Pipe Size).
• Drainage: Each compartment has a recessed 3 1/2” diameter drain hole. A 1 1/2” IPS basket-type waste drain is included with the unit (shipped loose).

Yes, the utility sink is supplied with the primary components required for drainage, though they are shipped loose for final installation. This sink is designed for optimal performance in heavy-duty utility settings.

Drain Components:

• Each deep compartment features a 3 1/2-inch diameter recessed drain hole.
• A 1 1/2” IPS basket-type waste drain is included with the unit (shipped loose).

No, the Eagle Group MHC 2-Compartment Utility Sinks are not NSF approved.

This specific series is engineered for rigorous use in industrial, commercial, or laboratory settings where NSF certification is not a required prerequisite.

These heavy-duty sinks are built for exceptional durability, utilizing:

• 16 gauge stainless steel (available in Type 304 or 430).
• 13 3/8-inch deep compartments for substantial capacity.
• Welded 12-gauge leg gussets for superior structural stability.

Yes, the utility sink includes a robust, integrated backsplash designed to protect the adjacent wall and minimize splashing in heavy-use environments.

Key specifications of the backsplash:

• Height: 8 inches
• Design: Features a 2-inch return to the wall, set at a 45-degree angle.
• Containment: Includes a 1-inch upturn at the top edge to help maximize spill containment.

Yes, the Eagle Group utility sink is designed for straightforward installation and is compatible with standard commercial plumbing connections.

Key specifications include:

• Faucet Compatibility: Features three 1 1/8” diameter holes punched on standard 8-inch centers, ready to accommodate most commercial faucets.
• Water Supply: Designed for 1/2” IPS hot and cold water supply lines.
• Drainage: Each deep compartment features a recessed 3 1/2” diameter drain hole and comes with a 1 1/2” IPS basket-type waste drain (shipped loose).
