Eagle Group MHC 2-Compartment Sinks, 314 Series Coved Corner

Yes, this commercial sink is constructed primarily from heavy gauge Type 304 stainless steel, which is highly valued for its superior resistance to corrosion and exceptional durability in demanding institutional and medical settings.

This robust material is used for the entire upper sanitary assembly, ensuring longevity and compliance with high hygiene standards. Key construction features include:

• Seamless Bowls: The two sink bowls are fabricated using deep-drawn, one-piece seamless construction with generous coved corners for maximum strength and ease of cleaning.
• Positive Drainage: The top surface incorporates V-creased drainboards and swirl-away drainage to ensure efficient water flow.
• Support Structure: The sink is stabilized by robust 1 5/8” diameter heavy-gauge galvanized tubing legs, reinforced with plated 12-gauge gussets and corrosion-resistant, adjustable bullet feet.

The bowls feature deep-drawn, one-piece seamless construction from heavy gauge Type 304 stainless steel, ensuring maximum hygiene and durability. They also include generous radius corners (minimum 3 inches) for easier cleaning. The standard water level is 13 1/2 inches.

This two-compartment sink is available with four different bowl size options:

• 20 inches x 16 inches
• 20 inches x 18 inches
• 22 inches x 22 inches
• 24 inches x 24 inches

Yes, the drainboards on the 314 Series sinks are specifically engineered to ensure positive and highly efficient drainage, which is crucial for maintaining hygiene in commercial and industrial settings.

Key features that guarantee reliable performance include:

• V-Creased Design: The drainboard surface features a specialized “V” creased configuration that actively directs water flow.
• Swirl-Away Drainage: This system facilitates rapid water movement, preventing standing water and channeling it directly into the sink bowls.
• Type 304 Stainless Steel: The drainboards are built from the same heavy-gauge, durable Type 304 stainless steel used for the sink bowls and top, ensuring exceptional corrosion resistance and longevity.

Depending on your configuration needs, the sinks are available with 18-inch or 24-inch drainboards located on the left or right side, or without drainboards entirely.

The Eagle Group 314 Series sinks feature a deep-drawn, one-piece seamless bowl construction made from heavy gauge Type 304 stainless steel. This design incorporates coved corners and a generous radius (minimum 3”) to ensure maximum strength and hygiene.

Key advantages of this construction include:

• Superior Sanitation and Easy Cleaning: The seamless design and coved corners eliminate internal corners and crevices where dirt and debris accumulate. This greatly simplifies maintenance and supports the stringent sanitation standards required in industrial and medical environments.
• Enhanced Durability: The deep-drawn, one-piece fabrication process, created using hydraulic presses, maximizes the structural integrity of the heavy gauge Type 304 stainless steel, ensuring exceptional longevity and resistance to leaks in demanding, heavy-duty use.
• Optimized Capacity: The seamless, rectangular shape provides an optimized design for maximum usable water capacity.

Yes, this heavy-duty sink features an integrated, robust backsplash constructed from heavy gauge Type 304 stainless steel, ensuring superior durability and corrosion resistance. The design is optimized for hygiene and permanent installation.

Key Backsplash Features:

• Standard Height: 9 1/2 inches.
• Upturn: Includes a 1-inch upturn at the top edge.
• Design: Features a tile edge designed for seamless integration and sealing against wall surfaces.

The sink comes standard with a reliable basket-type waste drain for each compartment, designed for high-efficiency water removal.

Key features ensuring effective drainage include:

• Drain Specifications: The included waste drain fits a 3 1/2” sink opening and features a 1 1/2” outlet.
• Bowl Technology: The deep-drawn, seamless bowls utilize Swirl-away drainage to facilitate rapid and complete water evacuation.
• Drainboard Feature: If your configuration includes drainboards, they are V-creased to ensure positive drainage and prevent standing water.

Yes, this heavy-duty commercial sink is designed with pre-punched holes to accommodate standard commercial plumbing fixtures.

Here are the specific dimensions for faucet installation:

• Faucet Hole Size: 1 1/8 inches in diameter
• Spacing: The holes are punched on 8-inch centers, a configuration standard for most commercial deck-mount faucets.
• Water Supply Connection: The sink is ready for 1/2” IPS hot and cold water lines.

Yes, this sink is engineered for maximum stability and can be easily leveled on uneven surfaces, making it reliable in demanding commercial or industrial settings.

The robust support system features:

• Fully Adjustable Bullet Feet: The sink rests on high-impact, corrosion-resistant, fully adjustable bullet feet. These allow you to precisely level the unit, ensuring maximum stability regardless of floor irregularity.
• Heavy-Duty Legs: The support framework uses 1 5/8” diameter heavy-gauge galvanized tubing legs.
• Reinforced Structure: Stability is further enhanced by plated 12-gauge gussets and 1” diameter galvanized crossbracing, strategically welded adjacent to the sink bowl.

The standard water level for the deep-drawn, seamless sink bowls is 13 1/2 inches. This generous depth is designed to provide maximum usable capacity for heavy-duty commercial washing and sanitation tasks.

Yes, the Eagle Group MHC sink is built with an exceptionally robust support structure designed for demanding commercial and industrial environments.

Its stability and durability are ensured by the following heavy-duty components:

• Legs: Constructed from 1 5/8” diameter heavy-gauge galvanized tubing.
• Gussets: Reinforced with plated 12-gauge gussets that are securely welded adjacent to the sink bowls for maximum stability and load support.
• Crossbracing: Utilizes 1” diameter heavy-gauge galvanized tubing for enhanced structural integrity.
• Feet: Includes fully adjustable, high-impact, corrosion-resistant bullet feet to ensure stable placement, even on uneven floors.
