Condition:
Factory New
- Country of Origin: USA
-
Warranty:
2 Years
- Weight: 0.15 lb
- Dymedix products are available to U.S. customers only
- Used to help aid in the detection of paradoxical respiratory movement
- Plugs directly into RIP inputs
- No woven wire belts and the low profile buckles ensure patient comfort
-
Learn more:
-
MFR:
Dymedix
Ships from MFI Medical
- MPN: 11-22406-0301
- Phone: (763) 789-8280
+Free Shipping*
Shop with Confidence
Free Shipping
Free Returns
Sales Tax Exemption
+Dedicated Account Managers
Frequently asked questions
Is this sensor specifically designed for pediatric patients?
The Dymedix PerfectFit 2 R/S Effort Belt Abdomen Sensor is specifically designed for pediatric patients to detect paradoxical respiratory movement. It connects directly to RIP inputs, ensuring compatibility with standard respiratory monitoring equipment.
How is this sensor designed for patient comfort?
The Dymedix PerfectFit 2 R/S sensor prioritizes patient comfort, which is crucial for pediatric sleep studies. The design facilitates quick setup and promotes better adherence during extended monitoring periods.
Key comfort elements include:
- Low-Profile Buckles: These are incorporated for quick and easy setup, minimizing bulk and potential irritation points.
- Absence of Woven Wire Belts: The design avoids traditional, rigid woven wire belts, ensuring the strap material remains comfortable and flexible against the child’s skin.
Does this belt use high-speed PVDF sensor technology?
Yes, the Dymedix PerfectFit 2 R/S Effort Belt uses highly sensitive Polyvinylidene Fluoride (PVDF) sensor technology for superior performance in pediatric respiratory monitoring. It aids in the detection of paradoxical respiratory movement.
Key advantages of the PVDF technology include:
- Extremely Fast Response: The PVDF sensor transmits signals approximately 1,000 times faster than traditional thermistors, ensuring immediate data relay.
- High Sensitivity: The PVDF film reacts to both temperature change and pressure.
- AASM Compliance: The sensor technology fully complies with the technical specifications set by the American Academy of Sleep Medicine (AASM).
- Patient Comfort: The design prioritizes comfort with low-profile buckles and the absence of woven wire belts for quick, easy setup.
What are the typical polygraph settings?
The Dymedix PerfectFit 2 R/S Effort Belt is designed for direct interface with RIP inputs. The recommended typical polygraph settings for optimal respiratory effort detection are:
- Sensitivity: 100 to 300 µV/mm
- Low Frequency Filter: 0.1 Hz
- High Frequency Filter: 15 Hz
Additionally, the typical signal amplitude is 1 mV peak to peak. Please note that the actual signal amplitude can vary based on sensor position, strap tension, and the specific polygraph equipment characteristics.
What are the dimensions and cable length of the sensor?
The sensor dimensions are 6.25 inches (L) x 1.25 inches (H). The cable length is 60 inches, providing sufficient reach for connecting to monitoring equipment.
What are the operating and storage ranges for this sensor?
The Dymedix PerfectFit 2 R/S Effort Belt Abdomen Sensor operates within a temperature range of 40 to 104 °F and can be stored at temperatures from -4 to 140 °F. Both operating and storage humidity should be between 5 to 95% (non-condensing).
What type of equipment is this sensor compatible with?
The sensor connects directly to RIP (Respiratory Inductance Plethysmography) inputs. It is designed to integrate seamlessly with standard sleep monitoring systems and polygraphs that utilize RIP technology for measuring respiratory effort.
Does this sensor accurately detect paradoxical respiratory movement?
Yes, the Dymedix PerfectFit 2 R/S Effort Belt Abdomen Sensor is designed to aid in the detection of paradoxical respiratory movement. It plugs directly into RIP inputs for seamless integration.
