Chattanooga Galaxy TTET400 Traction Table

The Chattanooga Galaxy TTET400 Traction Table is a multifunctional table that has four independent sections and is designed to be used for traction treatments. Available in six colors.

Warranty:

• Cushion and Upholstery - 1 Years.
• Base Frame and Motor - 2 Years.

The Chattanooga Galaxy TTET400 Traction Table is equipped with a roller-mounted surface and comfortable upholstery that prevents friction below the hips and legs. This enables patients to get the most benefit from their spinal traction treatment, as the rolling sections can be locked. Height adjustmeent is easy and smooth, thanks to the scissor frame and electric HalloTronic + System. The table can support a weight capacity of 440 lb (with a maximum workload of 605 lb).

 This table is ideal for both prone and supine positions when it comes to manual or traction therapy. When not in use, it can also function as a standard treatment table.

Chattanooga Galaxy TTET400 Traction Table Features

• Includes four multidirectional, retractable wheels for transporting.
• HalloTronic + System enables quick and easy high/low height adjustment.
• Roller-mounted surface with lockable sections for stability and comfort.

Chattanooga Galaxy TTET400 Traction Table Specifications

• Mains Power: 120 V, 50/60 Hz.
• Current: Max 2A with 120 V.
• Dimensions:
  • Head Section: 23".
  • Middle Section: 8".
  • Pelvic Section: 9.8".
  • Leg Section: 47".
  • Width: 27.5".
  • Total Table Length: 79.5".
  • Total Length with Traction Platform: 103".
• Adjustment:
  • Angle Inclination:
    • Head: -10 degrees to +82 degrees.
    • Leg: 0 degrees to 73 degrees.
  • Displacement: Leg: 6".
  • Height:
    • Minimum: 19".
    • Maximum: 39".
• Dynamic Lifting Capacity: 440 lb.
• Maximum Workload: 605 lb.
• Electrical Safety Class: Class I, Type B.
• Safety Tests: CE, Class I Rule 12.
• Shipping Weight: 330 lb.
• Shipping Dimensions: 86.6" x 33.5" x 31.5".
• Table Weight: 274 lb.

Chattanooga Galaxy TTET400 Traction Table Colors

• #3267102US: Blue.
• #3267108US: Black.
• #3267101US: Beige.
• #3267106US: Gray.
• #3267107US: Graphite Gray.
• #3267119US: Imperial Blue.

Chattanooga Galaxy TTET400 Traction Table Accessories

Please note, the following items are NOT included with purchase of the table. These are commonly purchased as optional accessories for the table.

• #8200: Chattanooga TTET400 / TTET300 Traction Unit Kit with Stool. (Available in six stool colors).
• #8206: Chattanooga TTET400 / TTET300 Traction Unit Kit with Bolster.

Chattanooga Galaxy TTET400 Traction Table Literature

Chattanooga General Line Traction Catalog
