- Country of Origin: USA
- Weight: 18.6 lb
- Adjustable flow control allows suction to be adjusted in 10% increments
- Filter tracking technology automatically tracks and records filter life through a patented technology
- LED display indicates filter life and suction power
- Ideal for veterinarian and non-acute care settings where moderate flow is necessary
-
Learn more:
- MFR: ConMed Ships from Manufacturer
- MPN: PPS604
- Phone: (866) 426-6633
Frequently asked questions
What specialized filter series are compatible?
The Porta PlumeSafe 604 is compatible with multiple specialized Buffalo Filter series designed for efficient surgical smoke evacuation, suitable for moderate flow applications.
The compatible filter series include:
- VS06
- VSXLL
- VSXLLT
- VSEY
- VSOH
- VSVET Series
To maximize filter longevity and performance, the unit is equipped with a ViroSafe Fluid Trap to capture fluids before they reach the main filter. Additionally, patented technology automatically tracks and records filter life, providing clear status updates (NEW, REPLACE, SERVICE) on the LED display.
Is a pneumatic footswitch included?
Yes, the Porta PlumeSafe 604 Surgical Smoke Evacuator includes a pneumatic footswitch as a standard accessory. This allows for convenient, hands-free control during medical procedures.
Is the smoke evacuator operation quiet?
Yes, the Buffalo Filter Porta PlumeSafe 604 is designed for quiet operation. It maintains nominal noise levels of less than 59 dBA when running at maximum power, ensuring minimal disruption in veterinarian and non-acute care settings.
Where is the Porta PlumeSafe 604 evacuator ideal?
The Buffalo Filter Porta PlumeSafe 604 is specifically designed for environments requiring moderate flow surgical smoke evacuation. It is ideal for use in the following settings:
- Veterinarian clinics: Providing necessary smoke control during procedures.
- Non-acute care settings: Suitable for procedures where moderate flow is sufficient.
- Portable/mobile clinical applications: Its compact design and lightweight construction (22 lb with filter) facilitate easy transport and stable tabletop placement.
Does the 604 offer precise suction adjustment?
Yes, the Porta PlumeSafe 604 features highly adjustable flow control. You can precisely adjust the suction power in 10% increments using the dedicated controls located on the front panel. This flexibility allows users to finely tune performance based on their specific procedural requirements.
What flow rates does the unit achieve?
The Porta PlumeSafe 604 provides moderate-flow evacuation capabilities. The maximum flow rate achieved depends on the diameter of the tubing used:
| Tubing Size | Flow Rate (Nominal) |
|---|---|
| 1-1/4” (32 mm) | 48 cfm (1358 lpm) |
| 7/8” (22 mm) | 36 cfm (1019 lpm) |
How compact are the dimensions?
The Porta PlumeSafe 604 features a highly portable, compact design, making it suitable for stable tabletop use or easy transport in veterinary and non-acute care settings. Its dimensions and weight emphasize this portability:
- Dimensions (W x D x H): 10” x 6.5” x 18” (25 cm x 17 cm x 46 cm)
- Weight (Without Filter): 18.6 lb (8 kg)
- Weight (With Filter Installed): 22 lb (9 kg)
Does the unit include the ViroSafe Fluid Trap?
Yes, the Porta PlumeSafe 604 includes the ViroSafe Fluid Trap. This is an essential component designed to enhance the longevity and performance of your primary filter.The ViroSafe Fluid Trap provides several critical benefits:* Captures Fluids: It collects fluids generated during surgical procedures before they reach the main filtration system.* Protects Integrity: By preventing liquid contamination, it maintains the integrity of the internal filtration system.* Extends Filter Life: Protecting the primary filter from moisture ingress helps maximize its lifespan and efficiency, saving replacement costs.
Is the Porta PlumeSafe 604 easily portable?
Yes, the Porta PlumeSafe 604 is specifically designed for portability and easy transport, making it an excellent choice for veterinarian and non-acute care settings. It supports stable tabletop placement and is easy to move thanks to its compact and lightweight design.
Key features that ensure maximum portability include:
- Lightweight Construction: The unit weighs only 18.6 lb (8 kg) without the filter installed, or 22 lb (9 kg) with the filter.
- Compact Dimensions: It measures 10” W x 6.5” D x 18” H (25 cm x 17 cm x 46 cm).
- Easy Handling: It includes a durable, top-mounted carrying handle for convenient transport.
