- Weight: 0.04 lb
- Used as a replacement for a number of different Diagnostix instruments
-
Learn more:
-
MFR:
American Diagnostic Corporation
Ships from MFI Medical
-
MPN: 5411-4X
- Phone: (800) 232-2670
Frequently asked questions
Is this replacement lamp widely compatible?
Yes, this 3.5V replacement lamp is designed for versatile compatibility with a wide range of American Diagnostic Corporation (ADC) Diagnostix instruments. It is an essential replacement component for maintaining the functionality of 3.5V handheld medical devices, including:
- Otoscopes
- Throat Illuminators
- Ophthalmoscopes (Coax and Coax Plus models)
- Dermascopes
Illumination Technology Options
You can select between two primary lamp technologies, which affect performance, longevity, and warranty:
| Technology | Mean Life Span | Warranty | Key Benefit |
|---|---|---|---|
| Xenon | ~15 hours | 2 Years | Traditional, reliable light source. |
| LED | 10,000 to 100,000 hours | Lifetime | Exceptional longevity and significantly lower power draw. |
Do LED lamps offer superior longevity?
Yes, the LED replacement lamps offer dramatically superior longevity and efficiency compared to the traditional Xenon options, significantly reducing the frequency of replacements and overall operational costs. The choice between technologies impacts both lifespan and warranty.
Here is a comparison of the mean life span and warranty by lamp type:
| Technology | Compatible Instruments | Mean Life Span | Warranty |
|---|---|---|---|
| Xenon | Otoscope, Ophthalmoscope | 15 hours | 2 Years |
| LED | Otoscope | 10,000 hours | Lifetime |
| LED | Dermascope, Throat Illuminator, Coax Plus Ophthalmoscope | Up to 100,000 hours | Lifetime |
In addition to the extended operational life, LED models are far more energy-efficient, which helps maximize the battery life of your 3.5V ADC diagnostic instruments.
What are the advantages of choosing LED lamps?
Choosing the LED variants for your 3.5V ADC diagnostic instruments offers significant advantages, including exceptional longevity, superior power efficiency, and a robust warranty.
1. Unmatched Lifespan
LED technology drastically reduces the frequency of lamp replacement compared to Xenon bulbs (which have a mean life span of only 15 hours). This translates to substantial maintenance savings and reliability:
| Instrument Type | LED Mean Life Span |
|---|---|
| Otoscope | 10,000 hours |
| Dermascope, Throat Illuminator, Coax Plus Ophthalmoscope | Up to 100,000 hours |
2. Superior Power Efficiency
LED lamps consume significantly less current, maximizing the battery life of your 3.5V handheld instrument. While Xenon variants draw 690 mA to 720 mA, LED variants reduce consumption to an efficient range of 28 mA up to 300 mA (depending on the specific instrument).
3. Lifetime Warranty
All LED replacement lamps are backed by a Lifetime warranty, providing long-term assurance for the performance and durability of your diagnostic equipment.
Is this only the replacement lamp?
Yes, this purchase includes only the Factory New replacement lamp unit.
This component is designed to service various 3.5V ADC Diagnostix instruments and is available in Xenon or high-endurance LED configurations, offering lifespans up to 100,000 hours for specific models.
Please note that this product does not include:
- The complete diagnostic instrument head (Otoscope, Ophthalmoscope, etc.)
- The instrument handle or power source.
What is the current draw for these lamps?
The current draw (power consumption) varies significantly depending on the illumination technology you choose. The LED lamp variants are highly energy-efficient, offering vastly superior battery performance compared to the traditional Xenon options.
Here is a detailed breakdown of the required current draw (in milliamperes, mA):
| Lamp Type & Instrument | Current Draw |
|---|---|
| Xenon Lamps (Higher Consumption) | |
| Otoscope / Throat Illuminator | 720 mA |
| Coax Ophthalmoscope | 690 mA |
| LED Lamps (Highly Efficient) | |
| LED Otoscope | 300 mA |
| LED Dermascope / Throat Illuminator | 28 mA |
| LED Coax Plus Ophthalmoscope | 29 mA |
What is the warranty for the lamps?
The warranty provided depends on the lamp technology you choose:
- Xenon Lamps: These replacement lamps come with a 2-Year Warranty.
- LED Lamps: These long-life variants (offering up to 100,000 hours of operational life for certain models) are backed by a comprehensive Lifetime Warranty.
Does this lamp fit only 3.5V ADC instruments?
Yes, this replacement lamp is designed exclusively for use with 3.5V ADC Diagnostix instruments. It is a direct factory replacement part and is not intended for instruments from other brands or those requiring different voltages.
The lamp ensures proper function across a variety of compatible 3.5V ADC models, including:
- Otoscopes
- Dermascopes
- Ophthalmoscopes (Coax)
- Throat Illuminators
It is specifically confirmed to replace lamps in models such as 5411, 5413, 5416, 5481, 5412, and 54122.
Does the lamp include a robust warranty?
Yes, the lamp includes robust warranty coverage, which varies significantly depending on the illumination technology you select:
- Xenon Variants: These lamps are covered by a standard 2-Year Warranty.
- LED Variants: These superior, longer-lasting lamps are backed by a comprehensive Lifetime Warranty.
Choosing the LED option provides exceptional longevity, with some models (Dermascope/Throat Illuminator) offering mean life spans up to 100,000 hours, which significantly minimizes maintenance needs.
Is this a brand new lamp?
The ADC Lamp is a factory new product, ensuring optimal performance and reliability for your diagnostic instruments.
Are these lamps specifically for 3.5V instruments?
Yes, these are replacement lamps designed specifically for ADC Diagnostix 3.5V handheld diagnostic instruments.
They ensure perfect compatibility and optimal illumination across several product lines, including:
- Otoscopes
- Dermascopes
- Ophthalmoscopes (Coax and Coax Plus)
- Throat Illuminators
These lamps are essential maintenance parts for professional equipment and are classified as Factory New.
